10m heat-shrink tubing 2.4mm>1.2mm green/yellow
Shipped in 1-3 Days (Mo-Fri)
€3.47*
The Offgridtec dispenser box (MPN: vk13) contains yellow-green heat-shrink tubing for electrical insulation and to protect cables, wires, and connections. The 2:1 shrink ratio ensures that the inner diameter is reduced to half its original size when heated, allowing the tubing to fit snugly around the respective cable. Depending on the model, the heat-shrink tubing is available in lengths of 5 m or 10 m and comes in a convenient dispenser box.
Versatile heat-shrink tubing for cable insulation and protection of electrical connections
- 2:1 shrink ratio
- Available in various diameters and in 5-m or 10-m lengths
- Convenient dispenser box for clean removal and easy handling
- Suitable for insulating cables and protecting electrical connections
- Flame-retardant and halogen-free material
- Low shrink temperature for easy application
- Protection against moisture, UV radiation, corrosion, and mechanical stress
- Yellow-green color for standard-compliant identification of ground connections
Typical Applications
- The heat-shrink tubing is suitable for, among other things:
- Cable insulation
- Repairing damaged cable insulation
- Protection of soldered and crimped connections
- Photovoltaic and solar systems
- RV and trailer electrical systems
- Automotive and motorcycle electrical systems
- Model making
- Industry and control panel construction
- DIY and workshop applications
The following sizes are available:
- 10 m heat-shrink tubing, green/yellow, 1.2 mm > 0.6 mm, 1:2
- 10 m heat-shrink tubing, green/yellow, 1.6 mm > 0.8 mm, 1:2
- 10 m heat-shrink tubing, green/yellow, 2.4 mm > 1.2 mm, 1:2
- 10 m heat-shrink tubing, green/yellow, 3.2 mm > 1.6 mm, 1:2
- 10 m heat-shrink tubing, green/yellow, 4.8 mm > 2.4 mm, 1:2
- 5 m heat-shrink tubing, green/yellow, 6.4 mm > 3.2 mm, 1:2
- 5 m Green/Yellow Heat-Shrink Tubing 9.5 mm > 4.8 mm 1:2
- 5 m Green/Yellow Heat-Shrink Tubing 12.7 mm > 6.4 mm 1:2
- 5 m heat-shrink tubing, green/yellow, 19.1 mm > 9.5 mm, 1:2
- 5 m Green/Yellow Heat-Shrink Tubing 25.4 mm > 12.7 mm 1:2
Reliable Protection and Clear Identification
When heated, the heat-shrink tubing fits evenly and tightly around cables or connection points. This reliably insulates electrical contacts while protecting them from moisture, dust, UV radiation, and corrosion. The yellow-green color scheme is particularly suitable for identifying protective conductors (PE) and facilitates clear identification within electrical installations. The material used is flame-retardant, halogen-free, and free of PBB, PBBO, and PBBE. The lead content is less than 10 ppm, and the cadmium content is less than 5 ppm.
Easy to Use
The shrinking process begins at a temperature of approximately 70 °C. A temperature of at least 100 °C is recommended for complete shrinkage. The heat-shrink tubing can be applied quickly and evenly using a heat gun or a suitable hot-air tool. It can be flexibly cut to the required length prior to installation.
Technical Data
- Color: Yellow/Green
- Available lengths: 5 m or 10 m (depending on model)
- Shrink ratio: 2:1
- Minimum shrink temperature: 70 °C
- Temperature for complete recovery: 100 °C
- Operating temperature: -55 °C to +125 °C
- Tensile strength: >14 MPa (ASTM D2671)
- Elongation at break: 400% (ASTM D2671)
- Eccentricity: <30% (ASTM D2671)
- Flammability: VW-1
- Volume resistivity: 10¹⁴ Ω·cm (IEC 93)
- Copper resistance: in accordance with UL224
- Heat aging/tensile strength: unchanged (>12 MPa)
- Elongation at break after heat aging (158 °C / 168 h): >350 %
- Material: halogen-free (PBB/PBBO/PBBE-free)
- Approvals: UL224 125 °C VW-1 600 V, RoHS-compliant
Scope of delivery
1x Offgridtec heat-shrink tubing, yellow/green, 2:1 (length and diameter according to selected model)
