Die Balkonkraftwerke von Offgridtec bieten eine praktische Lösung, um einen Teil des benötigten Stroms für den Haushalt selbst zu erzeugen und dadurch die Kosten für den Gesamtstromverbrauch erheblich zu reduzieren. Das System umfasst zwei Solarmodule, einen geeigneten Micro-Wechselrichter sowie ein AC-Anschlusskabel, das den Wechselrichter mit einer Steckdose verbindet. Die Module sind so ausgelegt, dass sie direkt nebeneinander installiert werden können. Wie funktioniert ein Balkonkraftwerk? Das Offgridtec Balkonkraftwerk ist eine platzsparende Solaranlage, die aus einem Solarmodul und einem passenden Hoymiles Microwechselrichter besteht, um den erzeugten Strom in das hauseigene Stromnetz einzuspeisen. Der Wechselrichter wird idealerweise direkt an der Unterkonstruktion des Solarmoduls angebracht und mit dem Solar-Steckverbinder am Modul verbunden. Das AC-Kabel wird über den Battery-Anschluss des Wechselrichters angeschlossen und direkt zur passenden Steckdose geleitet. Dabei kann zwischen einer herkömmlichen Schuko-Steckdose und einer Wieland-Einspeisesteckdose, die im Lieferumfang enthalten ist, gewählt werden. Es ist keine spezielle Einstellung erforderlich, um den erzeugten Solarstrom im Stromnetz des Hauses zu nutzen. Wenn Strom von anderen Quellen im Haus vorhanden ist, wird dieser bevorzugt genutzt und bei Bedarf durch Netzstrom ergänzt. Das Balkonkraftwerk Komplettsystem enthält: 2x Trina Solar Vertex S TSM-DE09.08 425W Solarmodul monokristallin (Black Frame) 1x Hoymiles HM-600 Microinverter 1x 5m Anschlusskabel Betteri BC01 Buchse zu Schukosteckdose 1x Betteri Endkappe für BC01 Buchse IP67 Female Trina Solar Vertex S 425W Solarmodul Das Trina Solar Vertex S ist ein 425W Solarmodul mit monokristallinen Zellen und High-Density-Zellverbindungstechnologie. Verglichen mit dem Trina Vertex S 400W der ersten Generation, kann das verbesserte 425W Solarmodul mehr Energie kostengünstiger erzeugen, was den außergewöhnlichen Wert des Systems unter Beweis stellt. Seine Multi-Busbar-Technologie sorgt für mehr Absorption, geringen Serienwiderstand, verbesserte Stromableitung und erhöhte Zuverlässigkeit. Das Trina Solar Vertex S ist für den Einsatz bei Wind- und Schneelasten von 4000 - 6000 Pa (Testlasten) zertifiziert. Das hochtransparente und hitzevorgespannte Glas weist eine Dicke von 3,2mm auf und verfügt über eine Antireflexion-Beschichtung. Der Rahmen verfügt über eine 30mm eloxierte Aluminiumlegierung. Eigenschaften Multi-Busbar-Technologie Hoher Wirkungsgrad von 21,3% Hersteller Produktgarantie: 15 Jahre Verbesserte Energieerzeugung Inkl. Anschlusskabel Exzellentes Schwachlichtverhalten (IAM) Leichte Handhabung Flexible Installationslösungen für den Systemeinsatz Multi-Busbar-Technologie Busbars befinden sich auf jedem PV Modul. Es handelt sich dabei um Stromschienen, die auf jeder Solarzelle fest aufgedruckt sind. Sie nehmen den erzeugten Gleichstrom auf und führen diesen zu den Sammelschienen. Durch die Verwendung von mehr Busbars reduziert Trina Solar die Abschattung, verkürzt die Transportwege und verringert den Widerstand in den Modulen. Technische Daten Leistung (Pmax): 425 W Spannung (Vmp): 42,2 V Max. Strom (Imp): 10,08 A Leerlaufspannung Voc): 50,2 V Kurzschlussstrom (Isc): 10,61 A Betriebstemperatur: -40°C - +85°C Max. Systemspannung: 1500V DC Zellenwirkungsgrad: 21,3% Anzahl Zellen: 144 Abmessungen: 1762 x 1134 x 30 mm Gewicht: 21,8 kg Schutzart Anschlussdose: IP68 Hoymiles HM-600 Modulwechselrichter Der HM-600 von Hoymiles ist der perfekte Mikrowechselrichter für Ihr Ihr Balkonkraftwerk und eignet sich für die Solarstromproduktion mit einem Solarpanel bis zu einer Leistung von 500 Watt Peak. Genauso wie bei allen anderen Mikrowechselrichtern von Hoymiles ist er für lange Betriebsstunden und breiter PV-Modulanwendung geeignet, da seine Inbetriebnahme sehr niedrig (nur 22V) und der DC-Eingangsbereich der Betriebsspannung (16-60V) extrem breit ist. Der Hoymiles-Mikrowechselrichter wandelt den gewonnenen Solarstrom Ihrer Photovoltaik-Anlage, AC-Netz-konform um und speist ihn direkt in das Versorgungsnetz ein. Die einzigartige Konfiguration bewirkt, dass jedes PV-Modul von einem individuellen Maximum Peak Power Point Tracker (MPPT) gesteuert wird. Dadurch wird sichergestellt, dass unabhängig von der Leistung der anderen PV-Module in der Anlage die maximal verfügbare Leistung von jedem einzelnen Modul in das Versorgungsnetz gespeist wird. Wenn also einzelne PV-Module der Anlage durch Verschattung, Verschmutzung, Ausrichtung oder Fehlanpassungen beeinträchtigt werden, gewährleistet der HM-600 trotzdem eine Spitzenleistung für sein zugehöriges PV-Modul. Das Ergebnis ist die maximal mögliche Energieproduktion Ihrer PV-Anlage. Empfohlene Modulleistung: bis zu 380W Max. Eingangsspannung: 60V Max. Eingangsstrom: 2*11,5A Nennausgangsleistung: 600VA Betriebsspannungsbereich: 16~60V Abmessungen (BxHxT): 250 x 170 x 28 mm Gewicht. 3kg Steckdosen-Anschluss Das Balkonkraftwerk enthält ein 5m langes AC-Verlängerungskabel mit Betteri BC01 Stecker, passend zum HM-600 Inverter, an einem Ende und einem gewinkelten Schuko-Stecker am anderen Kabelende. Damit ist der schnelle und unkomplizierte Anschluss an die, in Deutschland üblichen, Schukosteckdosen (Stecker-Typ F) möglich. Balkonkraftwerke in Deutschland Aktuell gibt es in Deutschland kein Gesetz oder Verordnung, in der die Erzeugung von Solarstrom für den reinen Eigenbedarf geregelt wird. Der Grenzwert von maximal 600W AC PV-Leistung ist ein Reservewert, der nach aktueller VDE-Norm in einen bestehenden Steckdosenkreis eines Hauses eingespeist werden kann, ohne diesen zu überlasten. Für eigenständige Stromkreise ohne zusätzliche Belastung wird nichts beschrieben. Jede elektrische Installation sollte VDE-Konform ausgeführt werden. Der Betrieb eines Balkonkraftwerks über die übliche Schuko-Steckdose ist jedoch grundsätzlich nicht verboten. Die Meldung bei der Bundesnetzagentur ist Pflicht. Jedoch sind noch keine Fälle von Ordnungsgeld bei Nichtmeldung von Balkonkraftwerken bekannt, sowie unüberwindbare Probleme mit Netzbetreibern. Die Einhaltung und Umsetzung von Normen und Pflichten obliegt dem Anlagenbetreiber. Hierzu sind bereits viele fachliche und auch juristische Informationen auf einschlägigen Websites zu finden.

The basicPremium-XL 150w Solaranlage 12v 24v from Offgridtec (mpn 4-01-010970), is based on a high-quality, monocrystalline 150 wp solar module and the convenient pwm-12/24-30a charge controller with LCD display. The basicPremium series also comes with a matching 8m solar connection cable (solar module to charge controller) and 1.5m battery connection cable - each from the Pro-Connect series. The average daily yield in the period from March to October is about 600 wh*. The solar power of the system can be easily increased by several modules later if your needs increase. The system offers all basic components needed to charge your battery with self-produced solar power. This combination makes it the perfect base for a variety of possible solar applications. High-quality basic set for a wide range of applications Offgridtec Solar sets of the basicPremium series consist of basic components that every self-sufficient solar power system needs, regardless of whether the system is to be used on a garden shed, the garage or in mobile applications. We constantly focus on high quality of all delivered components to ensure reliability and a long life expectancy of the system. Our 150w solar module is equipped with the best monocrystalline cells and is produced and tested using the latest manufacturing technology. The remaining components of the set also follow this quality standard: The plug & play connection cables "made in Germany" are designed to keep the installation effort as low as possible without compromising on the connection quality. The pwm-12/24-30a Pro charge controller, with its convenient display and up-to-date charging algorithms, ensures easy operation of the system and perfect charging of your batteries. The basicPremium family is a mature product that has proven itself thousands of times in practice and offers the ideal starting point for a wide range of applications. applications Solaranlage 12v or 24v dc power supply in garden sheds, allotments and similar objects self-sufficient systems for outdoor lighting applications self-sufficient monitoring and communication systems or weather stations charging of smartphones, tablets or other devices with 12v / 5v dc power supply Performance parameters at a glance average daily yield: 600 wh Expandability of solar power by using the same panel to max. 450 wp (at 24v = 750 wp) Available power outputs: 5v dc and 12v dc at the charge controller (230v only with optional voltage converter) Components of the basicPremium-XL 150w Solaranlage 12v 24v 1 x Offgridtec monocrystalline 12v 150 wp solar panel Rated power: 150 wp, part number: 3-01-018395 Operating voltage (Vmp) 23,9 v, operating current (Imp) 6,28 a equipped with high efficiency solar cells minimized power loss during shading due to integrated bypass diode solid: frame made of anodized aluminum + special tempered ESG solar glass MC4 connector, dimensions (WxLxH): 1350 x 590 x 35 mm, weight: 8,9 Kg 1 x PwM-12/24-30 Pro solar controller 12v/24v max. charging current 30 a, max. PV power at 12v / 24v system: 390 w / 780 w modern, 3-stage PwM charge control for gentle and efficient charging of your battery(ies) 3 battery types adjustable: agm, gel, and liquid lead acid intuitive operation via 2 buttons directly on the device large LCD display with numerous display options, including kwh meter 2 usb ports with a maximum output power of 2,4a Load output with numerous configuration options, e.g. for light control Temperature compensated battery charging (optional temperature sensor required) 1x 8m 2x6mm² solar connection cable controller/solar module TwIN cable, plug & play - ready for immediate use MC4 connector on solar module side, ferrules on charge controller side highest quality solar cable: TwIN cable wire cross section: 2x6mm², length: 8m 1x 1,5m 2x6mm² 30 a battery connection cable controller/battery Plug & Play - immediately ready for use wire cross section: 2x6mm², length: 1,5m including flat fuse holder with built-in 30 a aTO fuse ferrules on charge controller side, m8 ring terminals on battery side incl. battery pole terminals for connection to round pole terminals Flexible and very easy to install The system is very easy to install, even by people who have little experience with solar technology. The cables are all delivered plug & play, ready for connection. You only need to connect the components together and the power production can begin. Expandable, customizable like every system from Offgridtec, the basicPremium-S can also be individually adapted and modified to your requirements. Our technical sales department is looking forward to your inquiry. Please contact customer service for any costs that may be incurred. Scope of delivery: 1x Offgridtec 4-01-010970 basicPremium-XL 150w 12v 24v Solaranlage 1x instruction manual including all components listed above

Die Balkonkraftwerke von Offgridtec bieten eine praktische Lösung, um einen Teil des benötigten Stroms für den Haushalt selbst zu erzeugen und dadurch die Kosten für den Gesamtstromverbrauch erheblich zu reduzieren. Das System umfasst zwei Solarmodule, einen geeigneten Micro-Wechselrichter inkl. DTU-Kontrolleinheit sowie ein AC-Anschlusskabel, das den Wechselrichter mit einer Steckdose verbindet. Die Module sind so ausgelegt, dass sie direkt nebeneinander installiert werden können. Wie funktioniert ein Balkonkraftwerk? Das Offgridtec Balkonkraftwerk ist eine platzsparende Solaranlage, die aus einem Solarmodul und einem passenden Hoymiles Microwechselrichter besteht, um den erzeugten Strom in das hauseigene Stromnetz einzuspeisen. Der Wechselrichter wird idealerweise direkt an der Unterkonstruktion des Solarmoduls angebracht und mit dem Solar-Steckverbinder am Modul verbunden. Das AC-Kabel wird über den Battery-Anschluss des Wechselrichters angeschlossen und direkt zur passenden Steckdose geleitet. Dabei kann zwischen einer herkömmlichen Schuko-Steckdose und einer Wieland-Einspeisesteckdose, die im Lieferumfang enthalten ist, gewählt werden. Es ist keine spezielle Einstellung erforderlich, um den erzeugten Solarstrom im Stromnetz des Hauses zu nutzen. Wenn Strom von anderen Quellen im Haus vorhanden ist, wird dieser bevorzugt genutzt und bei Bedarf durch Netzstrom ergänzt. Das Balkonkraftwerk Komplettsystem enthält: 4x Trina Solar Vertex S TSM-DE09R.08 425W Solarmodul monokristallin (Black Frame) 1x Hoymiles HM-1500 Wechselrichter 1x Hoymiles DTU-WLite Datenübertragungs- und Kontrolleinheit 1x 5m Anschlusskabel Betteri BC01 Buchse zu Schukosteckdose 1x Betteri Endkappe für BC01 Buchse IP67 Female 2x Verbindungskabel MC4 zu MC4 6mm²  2m rot/schwarz Trina Solar Vertex S 425W Solarmodul Das Trina Solar Vertex S ist ein 425W Solarmodul mit monokristallinen Zellen und High-Density-Zellverbindungstechnologie. Verglichen mit dem Trina Vertex S 400W der ersten Generation, kann das verbesserte 425W Solarmodul mehr Energie kostengünstiger erzeugen, was den außergewöhnlichen Wert des Systems unter Beweis stellt. Seine Multi-Busbar-Technologie sorgt für mehr Absorption, geringen Serienwiderstand, verbesserte Stromableitung und erhöhte Zuverlässigkeit. Das Trina Solar Vertex S ist für den Einsatz bei Wind- und Schneelasten von 4000 - 6000 Pa (Testlasten) zertifiziert. Das hochtransparente und hitzevorgespannte Glas weist eine Dicke von 3,2mm auf und verfügt über eine Antireflexion-Beschichtung. Der Rahmen verfügt über eine 30mm eloxierte Aluminiumlegierung. Eigenschaften Multi-Busbar-Technologie Hoher Wirkungsgrad von 21,3% Hersteller Produktgarantie: 15 Jahre Verbesserte Energieerzeugung Inkl. Anschlusskabel Exzellentes Schwachlichtverhalten (IAM) Leichte Handhabung Flexible Installationslösungen für den Systemeinsatz Multi-Busbar-Technologie Busbars befinden sich auf jedem PV Modul. Es handelt sich dabei um Stromschienen, die auf jeder Solarzelle fest aufgedruckt sind. Sie nehmen den erzeugten Gleichstrom auf und führen diesen zu den Sammelschienen. Durch die Verwendung von mehr Busbars reduziert Trina Solar die Abschattung, verkürzt die Transportwege und verringert den Widerstand in den Modulen. Technische Daten Leistung (Pmax): 425 W Spannung (Vmp): 42,2 V Max. Strom (Imp): 10,08 A Leerlaufspannung Voc): 50,2 V Kurzschlussstrom (Isc): 10,61 A Betriebstemperatur: -40°C - +85°C Max. Systemspannung: 1500V DC Zellenwirkungsgrad: 21,3% Anzahl Zellen: 144 Abmessungen: 1762 x 1134 x 30 mm Gewicht: 21,8 kg Schutzart Anschlussdose: IP68 Hoymiles HM-1500 Modulwechselrichter Der HM-1500 von Hoymiles ist der perfekte Mikrowechselrichter für Ihr Balkonkraftwerk. Das kompakte Leichtgewicht (nur 3,75kg inklusive dem 2,06m AC-Kabel) eignet sich für die Solarstromproduktion mit bis zu vier Solarpanelen bis zu einer Leistung von je 470W. Genauso wie bei allen anderen Mikrowechselrichtern von Hoymiles ist er für lange Betriebsstunden und breiter PV-Modulanwendung geeignet, da seine Inbetriebnahme sehr niedrig (nur 22V) und der DC-Eingangsbereich der Betriebsspannung (16-60V) extrem breit ist. Empfohlene Modulleistung: bis zu 470W Max. Eingangsspannung: 60V Max. Eingangsstrom: 4*11,5A Nennausgangsleistung: 1500VA Betriebsspannungsbereich: 16~60V Abmessungen (BxHxT): 280 x 176 x 33mm Gewicht. 3,75kg Hoymiles DTU-WLite Die Hoymiles Gateway DTU-WLite ist eine Datenübertragungseinheit, die eine drahtlose 2,4G-Kommunikation verwendet, um Informationen und Daten von Mikrowechselrichtern zu sammeln und sie über WLAN-Technologie an das Hoymiles-Überwachungssystem S-Miles Cloud übermittelt. Mit Hilfe von Ihrem DTU-WLite können Sie Daten und Alarme auf Modulebene einfach lesen und den Fernbetrieb und die Fernwartung des Mikrowechselsystems jederzeit und überall über die Hoymiles S-Miles Cloud realisieren und speichern. Die Überwachungskapazität ist auf 4 Module begrenzt. Dadurch ist das System optimal für kleine PV-Anlagen geeignet. Hinweis: DTU-WLite wird via 5V USB Netzteil an eine Hausstromsteckdose angeschlossen. Das Netzteil ist nicht im Lieferumfang enthalten. Es funktioniert mit nahezu allen USB Netzteilen, die Mindestens 1A Leistung abgeben können. S-Miles Accounterstellung Die Erstellung des S-Miles Accounts kann direkt vom Endnutzer vorgenommen werden. Im Downloadbereich dieses Artikels ist hierzu die Anleitung von Hoymiles zu finden. Steckdosen-Anschluss Das Balkonkraftwerk enthält ein 5m langes AC-Verlängerungskabel mit Betteri BC01 Stecker, passend zum HM-1500 Inverter, an einem Ende und einem gewinkelten Schuko-Stecker am anderen Kabelende. Damit ist der schnelle und unkomplizierte Anschluss an die, in Deutschland üblichen, Schukosteckdosen (Stecker-Typ F) möglich. Balkonkraftwerke in Deutschland Aktuell gibt es in Deutschland kein Gesetz oder Verordnung, in der die Erzeugung von Solarstrom für den reinen Eigenbedarf geregelt wird. Der Grenzwert von maximal 600W AC PV-Leistung ist ein Reservewert, der nach aktueller VDE-Norm in einen bestehenden Steckdosenkreis eines Hauses eingespeist werden kann, ohne diesen zu überlasten. Für eigenständige Stromkreise ohne zusätzliche Belastung wird nichts beschrieben. Jede elektrische Installation sollte VDE-Konform ausgeführt werden. Der Betrieb eines Balkonkraftwerks über die übliche Schuko-Steckdose ist jedoch grundsätzlich nicht verboten. Die Meldung bei der Bundesnetzagentur ist Pflicht. Jedoch sind noch keine Fälle von Ordnungsgeld bei Nichtmeldung von Balkonkraftwerken bekannt, sowie unüberwindbare Probleme mit Netzbetreibern. Die Einhaltung und Umsetzung von Normen und Pflichten obliegt dem Anlagenbetreiber. Hierzu sind bereits viele fachliche und auch juristische Informationen auf einschlägigen Websites zu finden.

The complete balcony power station systems from Offgridtec (MPN 014530) are an ideal way to produce some of the household electricity you need yourself and significantly reduce your overall expenditure on electricity. In addition to a solar module and matching micro inverter, the systems contain everything you need to connect to the household power grid and, if required, to mount on the balcony railing or roof. The set is designed for mounting the modules side by side. Our support team is on hand to provide advice and assistance for customised module installation options. How does a balcony power station work? The Offgridtec balcony power station is a compact solar power system. It consists of a solar module and the matching Hoymiles micro inverter for feeding into the household power grid. Ideally, the inverter is attached directly to the substructure of the solar module and connected to the solar module using the solar plug connector. The AC cable is connected via the Betteri connection of the inverter and routed directly to the appropriate socket. Here you can choose between connection to the standard Schuko socket or to a Wieland feed-in socket, which is included in the scope of delivery when selected. No special settings are required to utilise the solar power generated in the domestic power grid. If electricity is already available from local sources, the appliances in the household use this first and then supplement with mains power as required. The complete balcony power station system contains 2x Luxen Solar 430W Full Black Solar module Luxneri S5 1x Hoymiles HM-600 Microinverter 1x Connection cable Betteri BC01 socket to Schuko socket (length selectable 5m - 10m - 15m) Oder 1x Connection cable Betterie B01 socket to Wieland RST20I3S connection (length selectable 5m - 10m - 15m) Optionally selectable: Installation package for balcony railing - flat roof - plain tile roof - tiled roof - corrugated hernite and sheet metal roof (the respective sets contain 1.25 m long profile rails suitable for the balcony power station) Luxen 430W Luxneri Series 5 (Full Black) - Efficiency of 22% The monocrystalline and bifacial 430W Series N5 solar module from Luxen Solar impresses with a combination of different technologies, such as N-TOPCon cell technology and a 108 half-cell layout. SMBB half-cut cell technology was also used during production to increase performance. The state-of-the-art solar module represents the pinnacle of solar technology, offering impressive power output and low LCOE. The elegant full-black design makes it a good choice when it comes to finding a solar cell for rooftop installations on residential buildings or for balcony power plants and many other applications. Properties Glass-glass module N-TOPCon cell technology SMBB Half-Cut cell technology Low BOS & LCOE Bifacial cell module technology Excellent anti-PID and low LID performance 3 bypass diodes 30-year performance guarantee and 15-year product guarantee High cell efficiency of over 22% Half-cell technology In half-cell technology ("half-cut"), conventional silicon cells are cut in half using a laser. The resulting halves are then connected centrally in parallel, which leads to increased solar module output by reducing resistance losses. Bifacial cells Bifacial means two-faced. And the name says it all: the Luxen Solar 430W N5 module is also equipped with solar cells on the back, which means it can absorb sunlight even better and increases the efficiency of the overall module. Technical data Maximum power: 430W Module voltage (Vmp): 32.04V max. current (Imp): 13.42A open circuit voltage (Voc): 38.96V short-circuit current (Isc): 14.13A Module efficiency: 22.02% Dimensions: 1722 x 1134 x 30 mm Operating temperature range: -40°C to +85°C Cells: 108 (6x18) Max. operating voltage: 1500V DC Weight: 23.5kg Hoymiles HM-600 Microinverter Module inverter The HM-600 from Hoymiles is the perfect microinverter for your balcony power plant and is suitable for solar power production with a solar panel up to 500 watts peak power. As with all other Hoymiles microinverters, it is suitable for long operating hours and wide PV module applications, as its start-up is very low (only 22V) and the DC input range of the operating voltage (16-60V) is extremely wide. The Hoymiles micro inverter converts the solar power generated by your photovoltaic system in line with the AC grid and feeds it directly into the utility grid. Each Hoymiles micro inverter is connected individually to a PV module in your system. This unique configuration means that each PV module is controlled by an individual Maximum Peak Power Point Tracker (MPPT). This ensures that the maximum available power from each individual module is fed into the supply grid, regardless of the output of the other PV modules in the system. So if individual PV modules in the system are affected by shading, soiling, alignment or mismatching, the HM-600 still guarantees peak power for its associated PV module. The result is the maximum possible energy production from your PV system. Recommended module power: up to 380W Maximum input voltage: 60V Maximum input current: 2*11.5A Rated output power: 600VA Battery voltage range: 16~60V Dimensions (WxHxD): 250 x 170 x 28mm Weight: 3kg (including 2.06m AC cable) Connection set For the connection cable, you have the option of choosing between a connection for a normal earthed socket or a Wieland feed-in socket. If you choose the latter, the complete system includes an AC extension cable (length selectable) with a Betteri BC01 plug, suitable for the HM-600 inverter, at one end and an angled Schuko plug at the other end of the cable. This enables quick and uncomplicated connection to the Schuko sockets (plug type F) commonly used in Germany. If the Wieland variant is selected, the AC cable has an angled Wieland RST20I3S plug at the cable end for installation in accordance with current technical regulations (e.g. VDE standard AR-N-4105). The appropriate feed socket is then included in the scope of delivery. With the Wieland plug, the pins are not completely exposed, as with the Schuko plug, which minimises the risk of arcing between pin and socket and therefore the risk of overheating and fire. Optional mounting systems The Offgridtec balcony power stations are available with or without mounting sets. Mounting sets are available for: Balcony railings: with matching C-hooks Flat roof: inclination angle 10° - 60° Plain tile roof: with plain tile roof hooks Tiled roof: with 3-way adjustable roof hooks Corrugated hernite and sheet metal roof: with stainless steel hanger bolts Balcony power plants in Germany There is currently no law or ordinance in Germany that regulates the generation of solar power for purely domestic use. The maximum limit of 600W AC PV power is a reserve value which, according to the current VDE standard, can be fed into an existing socket circuit in a house without overloading it. Nothing is described for independent circuits without additional load. Every electrical installation should be VDE-compliant. However, the operation of a balcony power station via the standard earthed socket is not generally prohibited. Registration with the Federal Network Agency is mandatory. However, there are no known cases of fines for failure to register balcony power stations, or insurmountable problems with network operators. The system operator is responsible for complying with and implementing standards and obligations. A great deal of technical and legal information can already be found on relevant websites. Do you have further questions about balcony power stations and how they work? Contact us, we will be happy to help you.

Das Balkonkraftwerk von Offgridtec zeigt Dir eine leistungsstarke Lösung mit einer Gesamtleistung von 810W auf, mit der Du einen Teil des Strombedarfs für den Haushalt selbst erzeugen kannst. Dadurch lassen sich die Kosten für den Gesamtstromverbrauch erheblich reduzieren. Das System umfasst zwei hochwertige, bifaziale Glas-Glas-Solarmodule von Luxen mit jeweils 405W Leistung und fortschrittlichster Technologie. Zur Effizienzsteigerung gehört ein HM-600 Microinverter Modulwechselrichter von Hoymiles und eine DTU-Wlite Übertragungs- und Kontrolleinheit dazu. Diese sammelt Informationen und Daten von dem Wechselrichter und übermittelt sie mit WLAN-Technologie an das Hoymiles-Überwachungssystem S-Miles Cloud. Das Set enthält zusätzlich ein 10m langes Anschlusskabel mit einer Betteri BC01 Buchse zur Schukosteckdose, sowie eine Betteri Endkappe für BC01 Buchsen, um alles unkompliziert anschließen zu können. Bifaziales Glas-Glas Modul Hochwertige Energiegewinnung mit hoher MPPT-Genauigkeit Datenübertragung in Echtzeit Wie funktioniert ein Balkonkraftwerk? Das Offgridtec Balkonkraftwerk ist eine platzsparende Solaranlage, die aus einem Solarmodul und einem passenden Hoymiles Microwechselrichter besteht, um den erzeugten Strom in das hauseigene Stromnetz einzuspeisen. Der Wechselrichter wird idealerweise direkt an der Unterkonstruktion des Solarmoduls angebracht und mit dem Solar-Steckverbinder am Modul verbunden. Das 10m-Anschlusskabel wird über den Battery-Anschluss des Wechselrichters angeschlossen und direkt zur passenden Steckdose geleitet. Es ist keine spezielle Einstellung erforderlich, um den erzeugten Solarstrom im Stromnetz des Hauses zu nutzen. Wenn Strom von anderen Quellen im Haus vorhanden ist, wird dieser bevorzugt genutzt und bei Bedarf durch Netzstrom ergänzt. Das Balkonkraftwerk Komplettsystem enthält: 2x Luxen Solar 405W Mono Bifazial Glas-Glas Solarmodul S5 Full Black Half-Cut 1x Hoymiles HM-600 Microinverter Modulwechselrichter 1x Hoymiles DTU-WLite Datenübertragungs- und Kontrolleinheit 1x 10m Anschlusskabel Mikrowechselwichter mit Betteri BC01 Buchse zu Schukosteckdose (Stecker gewinkelt) 1x Betteri Endkappe Verschluss Kappe für BC01 Buchsen IP67 FeMale Luxen Glas-Glas S5 405W Das monokristalline und bifaziale Solarmodul 405W S5 von Luxen Solar (MPN: LNVB-405MD) überzeugt durch eine Kombination verschiedener Technologien, wie zum Beispiel der Dotierung mit dem Metall Gallium, die das Phänomen der lichtinduzierten Degradation vorbeugt. Zur Leistungssteigerung wurde bei der Produktion außerdem die Halbzellen-Technologie angewandt. Und der Hersteller Luxen vertraut auf sein Produkt: Er garantiert eine 30-jährige Lebensdauer. Auf einen Blick: das Luxen S5 Galliumdotierung reduzierte Hot-Spot Temperatur Half-Cut Zelltechnologie hoher Zellwirkungsgrad von über 20% 30 Jahre Leistungsgarantie und 12 Jahre Produktgarantie Verwendete Technologien Halbzellen: Bei der Halbzellen-Technologie ("Half-Cut") werden herkömmliche Silizium-Solarmodul mittels eines Lasers halbiert. Die entstandenen Hälften werden danach zentral parallel geschaltet, was durch die Verringerung von Widerstandsverlusten zu einer erhöhten Leistung des Solarmoduls führt. Bifaziale Zellen: Bifazial heißt übersetzt zweigesichtig. Und der Name ist Programm: Das Luxen Solar 405W Modul ist auch auf der Rückseite mit Solarzellen ausgestattet, wodurch das Sonnlicht noch besser aufgenommen werden kann und der Wirkungsgrad des Gesamtmoduls steigt. Gallium gegen lichtinduzierte Degradation - das bedeutet, dass Module beim ersten Lichtkontakt etwas an Effizienz verliert. Mit Gallium dotierte Solarzellen wie die von Luxen weisen jedoch auch nach längerer Sonnenbestrahlung noch eine hohe Spannung auf und sind stabiler als etwa mit Bor dotierte Zellen. Technische Daten maximale Leistung: 405W Modulspannung (Vmp): 31,62V max. Strom (Imp): 12,81A Leerlaufspannung (Voc): 37,74V Kurzschlussstrom (Isc): 13,70A Modulwirkungsgrad: 20,74% Abmessungen: 1722 x 1134 x 30 mm Betriebstemperaturbereich: -40°C bis +85°C max. Betriebsspannung: 1500V DC Anzahl der Zellen: 108 (6x18) Gewicht: 23,5 kg Hoymiles HM-600 Der HM-600 von Hoymiles ist der perfekte Mikrowechselrichter für Ihr Balkonkraftwerk. Das kompakte Leichtgewicht (nur 3kg inklusive dem 2,06m AC-Kabel) eignet sich für die Solarstromproduktion mit bis zu zwei Solarpanelen bis zu einer Leistung von je 380 Watt. Genauso wie bei allen anderen Mikrowechselrichtern von Hoymiles ist er für lange Betriebsstunden und breiter PV-Modulanwendung geeignet, da seine Inbetriebnahme sehr niedrig (nur 22V) und der DC-Eingangsbereich der Betriebsspannung (16-60V) extrem breit ist. Eigenschaften Minimierung der Auswirkungen von z.B. Verschattung, Staub oder Alterung durch MPPT Hochwertige Energiegewinnung mit hoher MPPT-Genauigkeit Optimale Systemzuverlässigkeit Spitzenwirkungsgrad von 96,7% 12 Jahre Produktgarantie Hohe Sicherheit durch integrierte Schutzfunktionen Einfache Installation Lange Lebensdauer 6000V Stromstoßschutz Entspricht VDE-AR-N 4105: 2018 & EN50549-1:2019 Optimale Zuverlässigkeit Mikro-Wechselrichtersysteme sind von Natur aus zuverlässiger als herkömmliche Wechselrichter. Der dezentrale Aufbau eines Mikrowechselrichtersystems stellt sicher, dass es bei einer Störung nicht zum Ausfall der gesamten PV-Anlage kommt. Hoymiles-Mikrowechselrichter sind für den Betrieb mit voller Leistung bei Umgebungstemperaturen von bis zu +65°C (150°F) ausgelegt. Das Gehäuse des Mikro-Wechselrichters ist für die Außeninstallation ausgelegt und entspricht der Schutzart IP67. Technische Daten Empfohlene Modulleistung: 240~380W (je Modul) Spitzenleistung MPPT des Spannungsbereichs: 29~48V Anlaufspannung: 22V Betriebsspannungsbereich: 16~60V Maximale Eingangsspannung: 60V Maximaler Eingangsstrom: 2*11.5A Maximaler Eingangskurzschlussstrom: 2*15A Nennausgangsleistung: 600VA Nennausgangsstrom: 2.61A bei 230V Nennausgangsspannung/-bereich: 230V (180-275V) CEC-gewichteter Wirkungsgrad: 96.50% Umgebungstemperaturbereich: -40~+65°C Abmessungen (BxHxT): 250 x 170 x 28 mm Gewicht: 3kg (einschließlich 2.06m AC-Kabel) Gehäuseeinstufung: IP67 DTU-WLite Die Hoymiles Gateway DTU-WLite ist eine Datenübertragungseinheit, die eine drahtlose 2,4G-Kommunikation verwendet, um Informationen und Daten von Mikrowechselrichtern zu sammeln und sie über WLAN-Technologie an das Hoymiles-Überwachungssystem S-Miles Cloud übermittelt. Die DTU ist mit der Hoymiles HM- und MI-Serie kompatibel. Mit Hilfe von Ihrem DTU-WLite können Sie Daten und Alarme auf Modulebene einfach lesen und den Fernbetrieb und die Fernwartung des Mikrowechselsystems jederzeit und überall über die Hoymiles S-Miles Cloud realisieren und speichern. Die Überwachungskapazität ist auf 4 Module begrenzt. Dadurch ist das System optimal für kleine PV-Anlagen geeignet. Hinweis: DTU-WLite wird via 5V USB Netzteil an eine Hausstromsteckdose angeschlossen. Das Netzteil ist nicht im Lieferumfang enthalten. Es funktioniert mit nahezu allen USB Netzteilen, die Mindestens 1A Leistung abgeben können. Eigenschaften Überwachung auf Modulebene, mit bis zu 4 Solarmodulen Einfache Installation dank Plug and Play Fernwartung des Systems über die S-Miles Cloud Direktanschluss (USB-Port) Daten und Alarme von Mikrowechselrichtern auf S-Miles Toolkit in Echtzeit LED-Anzeige S-Miles Accounterstellung Die Erstellung des S-Miles Accounts kann direkt vom Endnutzer vorgenommen werden. Im Downloadbereich dieses Artikels ist hierzu die Anleitung von Hoymiles zu finden. Technische Daten Typ: Proprietäres 2,4-GHz-Protokoll (Nordic) Maximale Entfernung (offenes Gelände und je nach Installationsumgebung): bis zu 150m Begrenzung der Überwachungsdaten von Solarmodulen: 4 Signal: WLAN:802.11b/g/n Abtastung: Alle 15 Minuten Lokale APP: S-Miles Toolkit Leistungsaufnahme Typ 1,0 W / max. 5,0 W Eingangsspannung: 5V Umgebungstemperaturbereich: -20 bis +55°C Abmessungen (BxHxT): 143 x 33 x 12,5 mm Gewicht: 0,1kg Zertifikat: CE Modell des Mikrowechselrichters: HM-Serie & MI-Serie Balkonkraftwerke in Deutschland Aktuell gibt es in Deutschland kein Gesetz oder Verordnung, in der die Erzeugung von Solarstrom für den reinen Eigenbedarf geregelt wird. Der Grenzwert von maximal 600W AC PV-Leistung ist ein Reservewert, der nach aktueller VDE-Norm in einen bestehenden Steckdosenkreis eines Hauses eingespeist werden kann, ohne diesen zu überlasten. Für eigenständige Stromkreise ohne zusätzliche Belastung wird nichts beschrieben. Jede elektrische Installation sollte VDE-Konform ausgeführt werden. Der Betrieb eines Balkonkraftwerks über die übliche Schuko-Steckdose ist jedoch grundsätzlich nicht verboten. Die Meldung bei der Bundesnetzagentur ist Pflicht. Jedoch sind noch keine Fälle von Ordnungsgeld bei Nichtmeldung von Balkonkraftwerken bekannt, sowie unüberwindbare Probleme mit Netzbetreibern. Die Einhaltung und Umsetzung von Normen und Pflichten obliegt dem Anlagenbetreiber. Hierzu sind bereits viele fachliche und auch juristische Informationen auf einschlägigen Websites zu finden.

The complete balcony power plant systems from Offgridtec (mpn 016030) are an ideal way to produce a portion of your required household electricity yourself and significantly reduce your overall expenditure on electricity. In addition to two 430w bifacial solar modules and a matching micro inverter, the systems contain everything you need to connect to the household power grid and, if required, to mount them on the balcony railing or roof. The set is designed for mounting the modules side by side. Our support team will be happy to provide you with advice and assistance for individual module installation options. How does a balcony power station work? The Offgridtec balcony power station is a compact Solaranlage. It consists of a solar module and the matching Hoymiles micro inverter for feeding into the household power grid. Ideally, the inverter is attached directly to the substructure of the solar module and connected to the solar module using the solar plug connector. the ac cable is connected via the inverter's Betteri connection and routed directly to the appropriate socket. Here you can choose between connection to the standard Schuko socket or to a Wieland feed-in socket, which is included in the scope of delivery when selected. No special settings are required to use the solar power generated in the domestic power grid. If electricity is already available from local sources, the appliances in the household use this first and then supplement with mains power as required. The complete balcony power station system contains: 2x Luxen Solar 430w Mono Bifacial Glass-Glass Solar Module Full Black Luxneri Series n5 1x Hoymiles hms-800w-2t micro inverter 1xHoymiles HMS connection cable Field Connector Plug&Play(length selectable 5m - 10m - 15m) Optionally selectable: Mounting package for Balcony railings - Flat roof - Plain tile roof - Tiled roof - Corrugated hernite and sheet metal roof (The respective sets contain suitable 1.20 m long profile rails for the balcony power station) Optionally selectable: myStrom WiFi Switch eu Luxen 430w luxpower series 5 (bifacial, full black) - efficiency of over 22% The monocrystalline and bifacial 430w Full Black Series n5 solar module from Luxen Solar (mpn lnvb-430nd) impresses with a combination of different technologies, such as N-TOPCon cell technology and a 108 half-cell layout. The smbb half-cut cell technology was also used in production to increase performance. The state-of-the-art solar module represents the pinnacle of solar technology, offering impressive power output and low LCOE. The glass-glass module also offers excellent anti-PID and low lid performance, as well as high hotspot resistance. Its elegant full-black design makes it the ideal choice for Solaranstallations on residential buildings, balcony power plants and many other applications. The manufacturer is confident in its product and guarantees a 30-year service life. about the 430w Luxen n5 solar module Glass-glass module N-TOPCon cell technology smbb Half-Cut cell technology Low bos & LCOE Bifacial cell module technology excellent anti-PID and low lid performance 3 bypass diodes 30-year performance guarantee and 15-year product guarantee high cell efficiency of over 22% Half-cell technology In half-cell technology ("half-cut"), conventional silicon cells are cut in half using a laser. The resulting halves are then centrally connected in parallel, which leads to an increased output of the solar module by reducing resistance losses. Bifacial cells Bifacial means two-faced. And the name says it all: the Luxen Solar 430w n5 module is also equipped with solar cells on the back, which means that sunlight can be absorbed even better and the efficiency of the overall module is increased. Technical data maximum output: 430w Module voltage (Vmp): 32.04V max. current (Imp): 13.42A Open circuit voltage (Voc): 38.96V Short-circuit current (Isc): 14.13A Module efficiency: 22.02% Dimensions: 1722 x 1134 x 30 mm Operating temperature range: -40°C to +85°C Cells: 108 (6x18) max. operating voltage: 1500v DC Weight: 23,5kg Hoymiles hms-800w-2t micro inverter with integrated WiFi The hms-800w-2t (mpn: hms-800w-2t) fromHoymiles is the perfect micro inverter for a balcony power plant. In addition to the integrated WiFi module in Industry+ quality to be mentioned here, the compact lightweight (only 3.2kg) is ideal for solar power production with up to two solar panels with an output of 320 to 540+w each. Just like all other micro inverters from Hoymiles, it is suitable for long operating hours and wide PV module applications, as its starting voltage is very low (only 22v) and the DC input range of the operating voltage (16-60V) is extremely wide. Features Integrated WiFi module Minimization of the effects of e.g. shading, dust or ageing by mppt High-quality energy generation with high mppt accuracy Optimum system reliability Peak efficiency of 96.7% 12-year product guarantee High level of safety thanks to integrated protective functions Simple installation Long service life Complies with vde-ar-n 4105: 2018, en 50549-1: 2019, vfr 2019, IEC/en 62109-1/-2, IEC/en 61000-6-1/-2/-3/-4, IEC/en 61000-3-2/-3 Two MPP trackers for optimum solar yields Maximum Power Point Tracker technology is used to generate the best possible yield from a Solarasystem. The mppt determines the optimum ratio between irradiance, module temperature and solar cell type over the course of the day. Thanks to the two MPP trackers in the hms-800w-2t, the optimum operating point for the two PV strings can be optimized separately. The two trackers work independently of each other and so, for example, shading on one string would have no effect on the second. Simple design PV systems with Hoymiles microinverters are very easy to plan. You do not need to install cumbersome conventional inverters. Each microinverter can be quickly mounted on the PV mounting frame or directly under the PV module. The PV module is connected to the microinverter directly on site, eliminating the risk of people being exposed to dangerously high DC voltage. Technical data Recommended module power: up to 320w - 540+W (per module) mppt voltage range: 16-60V Switch-on voltage: 22V Maximum input voltage: 65V Maximum input current: 2*14A Maximum input short-circuit current: 2*25A Rated output power: 800VA Rated output current: 3.48A Nominal output voltage/range: 230v / 180-275V CEC peak efficiency: 96.70% Ambient temperature range: -40 - +65°C Storage temperature range: -40°C - +85°C Dimensions (WxHxD): 261 x 180 x 35.1 mm Weight: 3.2 kg Housing classification: IP67 Number of mppt`s: 2 myStrom WiFi Switch eu The WiFi Switch eu from myStrom enables you to make smarter use of your electronic devices. Measure your electricity consumption and costs and let the WiFi Switch switch your devices on or off automatically. By timer, schedule or standby. With the myStrom app, you have full control over your devices, even if you are not on site. The WiFi Switch eu is also compatible with Amazon Echo, Google Assistant and many more. 1. Attach the device 2. open the myStrom app 3. Connect Technical data : max. power consumption: 16A Operating voltage: 120V Material: polyvinyl chloride Weight: 120g Dimensions: 87 x 150 x 87mm Optional mounting systems The Offgridtec balcony power stations are available with or without mounting sets. Mounting sets are available for: Balcony railings: with matching C-hooks Flat roof: Inclination angle 10° - 60° Plain tile roof: with plain tile roof hooks Tiled roof: with 3-way adjustable roof hooks Corrugated hernite and sheet metal roof: with stainless steel hanger bolts Balcony power plants in Germany There is currently no law or regulation in Germany governing the generation of solar power for purely domestic use. The maximum limit of 800w ac PV power is a reserve value which, according to the current VDE standard, can be fed into an existing socket circuit of a house without overloading it. Nothing is described for independent circuits without additional load. Every electrical installation should be VDE-compliant. However, operating a balcony power station via the standard earthed socket is not prohibited. Registration with the Federal Network Agency is mandatory. However, there are no known cases of fines for non-registration of balcony power stations or insurmountable problems with network operators. Compliance with and implementation of standards and obligations is the responsibility of the system operator. A great deal of technical and legal information can already be found on relevant websites. Do you have further questions about balcony power plants and how they work? Contact us, we will be happy to help you.

This balcony power station from Offgridtec presents you with a powerful solution with a total output of 810w, with which you can generate part of the electricity required for the household yourself. This significantly reduces the cost of overall electricity consumption. The system consists of two high-quality, bifacial glass-glass solar modules from Luxen each with an output of 405w and state-of-the-art technologies. To increase efficiency, an hms-800w-2t microinverter module inverter from Hoymilesis included. The set also includes a 10m long Hoymiles connection cable with a field connector for easy connection. Bifacial glass-glass module High-quality energy generation with high MPPT accuracy How does a balcony power plant work? The Offgridtec balcony power station is a space-saving Solaranstallation that consists of a solar module and a matching Hoymiles micro inverter to feed the electricity generated into the home power grid. Ideally, the inverter is attached directly to the substructure of the solar module and connected to the solar connector on the module. The 10m connection cable is connected via the battery connection of the inverter and routed directly to the appropriate socket. No special settings are required to use the solar power generated in the home's power grid. If electricity from other sources is available in the house, this is used preferentially and supplemented by mains power if required. The complete balcony power station system includes: 2x Luxen Solar 405w Mono Bifacial Glass-Glass Solar Module s5 Full Black Half-Cut 1x Hoymiles hms-800w-2t Microinverter Module Inverter 1x 10m connection cable micro inverter with one field connector Luxen glass-glass s5 405w The monocrystalline and bifacial solar module 405w s5 from Luxen Solar (mpn: LNVB-405MD) impresses with a combination of different technologies, such as doping with the metal gallium, which prevents the phenomenon of light-induced degradation. Half-cell technology was also used in production to increase performance. And the manufacturer Luxen is confident in its product: it guarantees a 30-year service life. At a glance: the Luxen s5 Gallium doping reduced hot-spot temperature Half-cut cell technology high cell efficiency of over 20% 30-year performance guarantee and 12-year product guarantee Half-cell technology With half-cell technology ("half-cut"), conventional silicon solar modules are cut in half using a laser. The resulting halves are then centrally connected in parallel, which leads to an increased output of the solar module by reducing resistance losses. Bifacial cells Bifacial means two-faced. And the name says it all: the Luxen Solar 405w module is also equipped with solar cells on the back, which means that the sunlight can be absorbed even better and the efficiency of the overall module is increased. Gallium against light-induced degradation Light-induced degradation - this means that modules lose some of their efficiency when they first come into contact with light. However, solar cells doped with gallium, such as those from Luxen, still have a high voltage even after prolonged exposure to sunlight and are more stable than cells doped with boron, for example. Technical data maximum output: 405w Module voltage (Vmp): 37.33V max. current (Imp): 10,85A Open circuit voltage (Voc): 44.42V Short-circuit current (Isc): 11.82A Module efficiency: 20.74% Dimensions: 1722 x 1134 x 30 mm Operating temperature range: -40°C to +85°C max. operating voltage: 1500v DC Weight: 23.5 kg Hoymiles HMS-800-2T The hms-800w-2t (mpn: hms-800w-2t) from Hoymiles is the perfect micro inverter for your balcony power station. In addition to the integrated WiFi module in Industry+ quality to be mentioned here, the compact lightweight (only 3.2kg) is ideal for solar power production with up to two solar panels up to an output of 320 to 540+w each. Just like all other micro inverters from Hoymiles, it is suitable for long operating hours and wide PV module applications, as its starting voltage is very low (only 22v) and the DC input range of the operating voltage (16-60V) is extremely wide. Features Integrated WiFi module Minimization of the effects of e.g. shading, dust or aging through MPPT High-quality energy generation with high MPPT accuracy Optimum system reliability Peak efficiency of 96.7% 12-year product guarantee High level of safety thanks to integrated protective functions Simple installation Long service life Complies with vde-ar-n 4105: 2018, en 50549-1: 2019, vfr 2019, IEC/en 62109-1/-2, IEC/en 61000-6-1/-2/-3/-4, IEC/en 61000-3-2/-3 Optimum reliability Micro inverter systems are inherently more reliable than conventional inverters. The decentralized design of a microinverter system ensures that a fault does not cause the entire PV system to fail. Hoymiles microinverters are designed to operate at full power in ambient temperatures up to +65°C (150°F). The housing of the micro inverter is designed for outdoor installation and complies with protection class IP67. Technical data Recommended module power: up to 320w - 540+W (per module) MPPT voltage range: 16-60V Switch-on voltage: 22V Maximum input voltage: 65V Maximum input current: 2*14A Maximum input short-circuit current: 2*25A Rated output power: 800VA Rated output current: 3.48A Nominal output voltage/range: 230v / 180-275V CEC peak efficiency: 96.70% Ambient temperature range: -40 - +65°C Storage temperature range: -40°C - +85°C Dimensions (WxHxD): 261 x 180 x 35.1 mm Weight: 3.2 kg Housing classification: IP67 Number of MPPTs: 2 S-Miles account position The S-Miles account can be created directly by the end user. The instructions from Hoymiles can be found in the download area of this article. Balcony power plants in Germany There is currently no law or ordinance in Germany that regulates the generation of solar power for purely personal use. The maximum limit of 600w ac PV power is a reserve value which, according to the current VDE standard, can be fed into an existing socket circuit of a house without overloading it. Nothing is described for independent circuits without additional load. Every electrical installation should be VDE-compliant. However, operating a balcony power station via the standard earthed socket is not prohibited. Registration with the Federal Network Agency is mandatory. However, there are no known cases of fines for non-registration of balcony power stations or insurmountable problems with network operators. Compliance with and implementation of standards and obligations is the responsibility of the system operator. A great deal of technical and legal information can already be found on relevant websites. Scope of delivery 1x 810W balcony power station Hoymiles hms-800w-2t with 2 x 405w bifacial glass modules

The balcony power stations from Offgridtec offer a practical solution for generating part of the electricity required for the household yourself, thereby significantly reducing the cost of overall electricity consumption. The system comprises two glass-glass solar modules, a suitable micro inverter including DTU control unit and an ac connection cable that connects the inverter to a socket. The modules are designed so that they can be installed directly next to each other. How does a balcony power plant work? The Offgridtec balcony power station is a space-saving Solaranstallation consisting of a solar module and a matching Hoymiles micro inverter to feed the electricity generated into the home's own power grid. Ideally, the inverter is attached directly to the substructure of the solar module and connected to the solar connector on the module. The ac cable is connected via the battery connection of the inverter and routed directly to the appropriate socket. You can choose between a conventional Schuko socket and a Wieland feed-in socket, which is included in the scope of delivery. No special settings are required to use the solar power generated in the home's power grid. If electricity from other sources is available in the house, this is used preferentially and supplemented by mains power if required. The complete balcony power station system contains: 4x Luxen Solar 405w Mono Bifacial Glass-Glass Solar Module s5 Full Black Half-Cut 1x Hoymiles hm-1500 inverter 1x Hoymiles DTU-WLite data transmission and control unit 1x 5m connection cable Betteri bc01 socket to Schuko socket outlet 1x Betteri End cap for bc01 socket ip67 Female 4x 3m 6mm² MC-4 connection cable plug/socket extension Luxen Solar s5 Mono bifacial glass-glass 405w solar module The monocrystalline and bifacial solar module 405w s5 from Luxen Solar (mpn: LNVB-405MD) impresses with a combination of different technologies, such as doping with the metal gallium, which prevents the phenomenon of light-induced degradation. Half-cell technology was also used in production to increase performance. And the manufacturer Luxen is confident in its product: it guarantees a 30-year service life. At a glance: the Luxen s5 Gallium doping reduced hot-spot temperature Half-cut cell technology high cell efficiency of over 20% 30-year performance guarantee and 12-year product guarantee Half-cell technology With half-cell technology ("half-cut"), conventional silicon solar modules are cut in half using a laser. The resulting halves are then centrally connected in parallel, which leads to an increased output of the solar module by reducing resistance losses. Bifacial cells Bifacial means two-faced. And the name says it all: the Luxen Solar 405w module is also equipped with solar cells on the back, which means that the sunlight can be absorbed even better and the efficiency of the overall module is increased. Gallium against light-induced degradation Light-induced degradation - this means that modules lose some of their efficiency when they first come into contact with light. However, solar cells doped with gallium, such as those from Luxen, still have a high voltage even after prolonged exposure to sunlight and are more stable than cells doped with boron, for example. Technical data maximum output: 405w Module voltage (Vmp): 37.33V max. current (Imp): 10,85A Open circuit voltage (Voc): 44.42V Short-circuit current (Isc): 11.82A Module efficiency: 20.74% Dimensions: 1722 x 1134 x 30 mm Operating temperature range: -40°C to +85°C max. operating voltage: 1500v DC Weight: 23.5 kg Hoymiles hm-1500 module inverter The hm-1500 from Hoymiles is the perfect micro inverter for your balcony power plant. The compact lightweight (only 3.75kg including the 2.06m ac cable) is suitable for solar power production with up to four solar panels with an output of up to 470w each. As with all other Hoymiles microinverters, it is suitable for long operating hours and wide PV module applications, as its start-up is very low (only 22v) and the DC input range of the operating voltage (16-60V) is extremely wide. Recommended module power: up to 470W Max. Input voltage: 60V Max. Input current: 4*11.5A Rated output power: 1500vA Operating voltage range: 16~60V Dimensions (WxHxD): 280 x 176 x 33mm Weight. 3,75kg Hoymiles DTU-WLite The Hoymiles Gateway DTU-WLite is a data transmission unit that uses 2.4G wireless communication to collect information and data from microinverters and transmits it to the Hoymiles monitoring system S-Miles Cloud via WLAN technology. With the help of your DTU-WLite, you can easily read data and alarms at module level and realize and store remote operation and maintenance of the microinverter system anytime and anywhere via the Hoymiles S-Miles Cloud. The monitoring capacity is limited to 4 modules. This makes the system ideal for small PV systems. Note:dTU-WLite is connected to a domestic power socket via a 5v usb power supply unit. The power supply unit is not included in the scope of delivery. It works with almost all usb power supply units that can deliver at least 1a power. S-Miles account status The S-Miles account can be created directly by the end user. The Hoymiles instructions can be found in the download section of this article. Socket connection The balcony power station includes a 5m long ac extension cable with Betteri bc01 plug, suitable for the hm-1500 inverter, at one end and an angled Schuko plug at the other end of the cable. This enables quick and uncomplicated connection to the Schuko sockets (plug type f) commonly used in Germany. Balcony power stations in Germany There is currently no law or regulation in Germany governing the generation of solar power for purely personal use. The maximum limit of 600w ac PV power is a reserve value which, according to the current VDE standard, can be fed into an existing socket circuit of a house without overloading it. Nothing is described for independent circuits without additional load. Every electrical installation should be VDE-compliant. However, operating a balcony power station via the standard earthed socket is not prohibited. Registration with the Federal Network Agency is mandatory. However, there are no known cases of fines for non-registration of balcony power stations or insurmountable problems with network operators. Compliance with and implementation of standards and obligations is the responsibility of the system operator. A great deal of technical and legal information can already be found on relevant websites.

The 860w balcony power plant from Offgridtec is based on two high-quality, monocrystalline 430w Vertex-s solar modules from Trina solarand the 1-phase neo 800m-x 800w micro inverter from Growattthe system also includes a suitable ac connection cable for the micro inverter and two mc-4 connection cables for the solar modules. The balcony power plants from Offgridtec offer a practical solution for generating part of the electricity required for the household and thus significantly reducing the costs for overall electricity consumption. how does a balcony power station work? The Offgridtec balcony power station is a space-saving solarasystem consisting of two solar modules and a matching Growatt micro inverter to feed the electricity generated into the household power grid. Ideally, the inverter is attached directly to the substructure of the solar module and connected to the solar connector on the module. The ac cable is connected via the battery connection of the inverter and routed directly to the appropriate socket. no special setting is required to use the solar power generated in the home's power grid. if power from other sources is available in the home, this is used preferentially and supplemented by grid power if necessary. The complete balcony power station system includes: 2x Trina solar Vertex s 430w dual glass solar module 1x Growatt neo 800m-x 800w micro inverter 2x Offgridtec 3m mc-4 connection cable 1x Growatt 5m neo 800-m-x ac connection cable Micro inverter Trina solar Vertex s 430w solar module The Trina solar Vertex is a 430w solar module with monocrystalline cells and dual glass technology. The multi-busbar technology ensures increased absorption, lower series resistance, improved current dissipation and increased reliability. The module is certified for use under extreme wind and snow loads of 4000 - 6000 Pa (tested loads). its highly transparent glass is 3.2 mm thick and has an anti-reflective coating. The frame is made of anodized aluminium alloy with a width of 30 mm. Features Multi-busbar technology Dual-glass design very low degradation High efficiency of 21.5% Manufacturer product guarantee: 15 years Improved performance very low degradation Universal solution for residential and C&I roofs Multi-busbar technology On each PV module there are busbars that serve as busbars and are permanently attached to each solar cell. they collect the generated direct current and transmit it to the busbars. Trina solar reduces the shadow effects, shortens the transport distances and minimizes the resistance in the modules by using a larger number of busbars. Technical data Power (Pmax): 430 w voltage (Vmp): 43.2 V Max. current (Imp): 9.96 A Open circuit voltage (Voc): 51.4 V Short-circuit current (Isc): 10.60 A Operating temperature: -40°C - +85°C Max. system voltage: 1500v DC Cell efficiency: 21.5% Number of cells: 144 Dimensions: 1762 x 1134 x 30 mm Weight: 21.1 kg protection class junction box: IP68 Communication: mc4 ev02 / Ts4 Growatt neo 800m-x 800w micro inverter The Growatt neo 800m-x is a single-phase micro inverter that has been specially developed for the trouble-free use of balcony power plants or minisolaranlagen. The inverter is characterized by its impressive efficiency of up to 96.5%. With 2 independent MPPT inputs and an impressive maximum PV output of 320w up to 540w, this inverter is ideal for smaller systems. In addition, the inverter offers a wiFi function that enables effortless system monitoring. Technical data Max. recommended PV power: 320w up to 540w+ Max. Input voltage: 60 V start voltage: 16 V Nominal DC voltage: 16-60 V MPPT voltage range: 28V-60V Max. Input current per mppt: 16A Max. Short-circuit current per mppt: 20 A ac rated power: 800 w ac rated voltage range: 230v (180-253V) Frequency range: 50/60 Hz (45-55Hz/55-65Hz) Nominal output current: 3.48 A Dimensions: 260 x 220 x 43mm Weight: 3.1 kg Operating temperature range: -40°C - +65°C protection class: IP67 Balcony power stations in Germany There is currently no law or ordinance in Germany that regulates the generation of solar power for purely domestic use. The maximum limit of 600w ac PV power is a reserve value which, according to the current VDE standard, can be fed into an existing socket circuit of a house without overloading it. Nothing is described for independent circuits without additional load. Every electrical installation should be VDE-compliant. However, the operation of a balcony power station via a standard Schuko socket is not prohibited. Registration with the Federal Network Agency is mandatory. However, there are no known cases of fines for non-registration of balcony power stations or insurmountable problems with network operators. Compliance with and implementation of standards and obligations is the responsibility of the system operator. A great deal of technical and legal information can already be found on relevant websites.

The bundle of the EcoFlow DELTA Pro Powerstation and a matching Offgridtec solar module (MPN 4-01-014615) provides the ideal power supply for camping and outdoor adventures, at home or as a backup solution in case of power failure. It is optionally available with two foldable 440W FSP-2 solar cases, two 400W EcoFlow solar bags or three 410W Luxen full black solar modules. Optionally, the SmartHome Panel, a spare battery or a second power station can also be selected. Characteristics: Ideal for use in camping and outdoor areas, on expeditions or as an emergency power supply Charging with solar energy Supply up to 14 consumers at the same time All components perfectly matched Quick and easy installation according to the Plug & Play principle Portable and lightweight design for all components The EcoFlow DELTA Pro + Offgridtec® solar panel bundle includes: 2x Offgridtec FSP-2 440W Foldable Solar Panel (Solar Case) + Adapter cable Anderson plug Series connection + Adapter cable Anderson to XT60 20cm Or: 2x Offgridtec Ecoflow 400W foldable solar panel (solar bag) + Ecoflow XT60 solar cable Or: 3x 410W Luxen Full black solar panel + Ecoflow XT60 solar cablel EcoFlow DELTA Pro Powerstation 3,6Wh Optional Addition: Ecoflow Delta Pro Extra Smart Battery Ecoflow Delta Smart Home Panel (Note: The installation of the EcoFlow Smart Home Panel must be carried out by a licensed electrician). EcoFlow DELTA Pro Powerstation With the DELTA Pro (MPN 50034008), EcoFlow presents the largest version of its premium DELTA series in the mobile power station range to date. With its numerous connection and charging options, this portable power station is a versatile all-rounder for use at home, as a backup in the event of a power failure or for camping and outdoor adventures. With its capacity of 3600Wh and the 3600W inverter, the DELTA Pro can power almost any appliance, such as kitchen appliances, lights, mobile phones and laptops or tools. With the DELTA Pro Smart add-on batteries, the capacity can even be extended by up to 7.2kWh (sold separately). Inputs and outputs of the EcoFlow DELTA Pro: AC charge input: Max. 2900W, 230V - 12.5A Car charge input: supports 12V/24V battery, standard 8A Solar charge input: 11-150V, max. 15A, max. 1600W AC output (4x): total 3600W (peak 7200W), 230V/16A Max. Device power supported by X-Boost: 4500W USB-A output (2x): 5V - 2.4A, max. 12W per port USB-A fast charging (2x): 5V/2.4A, 9V/2A, 12V/1.5A, max. 18W per port USB-C output (2x): 5/9/12/15/20V - 5A, max. 100W per port DC5521 output (2x): 12.6V - 3A, 38W per port Car charger output (1x): 126W - 12.6V/DC - max. 10A Anderson port (1x): 30A, 12.6V Supports W-Lan & Bluetooth Supports up to 2 DELTA Pro Smart Extra batteries & smart generator (sold separately) Technical data: Dimensions: 635 x 284 x 420 mm Weight: approx. 45 kg Warranty: 24 months manufacturer's warranty Capacity: 3600Wh Cell chemistry: LFP Lifetime: 3,500 cycles to 80% capacity - 6,500 cycles to 50% capacity Charging temperature: 0°C - +45°C Discharge temperature: -20°C - +45°C Choose between the FSP-2 440W, 400W EcoFlow or the 410W Luxen Panels!   FSP-2 440W EcoFlow 400W Luxen 410W Full Black Nominal power 440W 400W 410W Number of pages 4 x 110W 4 x 100W 1 x 410W Module voltage (Vmp) 40V 41V 31,83V Max. Charge current (Imp) 11A 9,8A 12,88A Open circuit voltage (Voc) 48V 48V 37,98V Short circuit current (Isc) 12A 11A 13,77A Cell efficiency >22,63% >22,4% 21% Dimensions closed 1072 x 547 x 90 mm 1068 x 620 x 24 mm 1722 x 1134 x 30mm Dimensions open 1072 x 2188 x 22,5 mm 1068 x 2390 x 24 mm 1722 x 1134 x 30 mm Weight 13,2 kg 15 kg 21kg The FSP-2 foldable solar panels are equipped with highly effective SunPower solar cells and can be set up within seconds with the integrated supports and always aligned to suit the position of the sun. When folded, the solar panels are easy to handle and quickly stowed away. The FSP-2 modules work with rear-contacted solar cells that generate efficiencies of over 22%. A 6m solar cable is included in the scope of delivery of the FSP-2 modules. With the compact, foldable design and a shoulder strap, you can easily carry the EcoFlow 400W solar panels to your campsite or store them in your camper van while you're on the road. The bag, to protect the module when not in use, quickly and easily converts into a handy stand to find just the right angle to catch the sun's rays. Connect the modules to any EcoFlow Delta power station to charge them efficiently. Thanks to the universal solar connectors, connection to third-party generators is also possible. The Luxpower 410W Full Black Series 5 solar module from Luxen Solar is a monocrystalline and modern module with gallium-doped technology and 108 half-cell layout. Thanks to the multi-busbar technology, three integrated by-pass diodes and the two-part arrangement of the cell strings, this solar panel offers high hot-spot resistance in solo operation and a solid current yield in strings with many modules, even in poor light and partial shading. The noble full-black design makes it a good choice when it comes to finding a solar cell for rooftop installations on residential buildings or for balcony power plants and many other applications. Optimal cabling The bundle includes all cables necessary to connect the Powerstation to the selected solar module. The EcoFlow 400W solar bags and the Canadian Solar 375W solar modules include an EcoFlow XT60 solar cable (3.5m). The FSP-2 solar bags include a connection kit. With the XT60 to Anderson Adapter, you connect the module's connection cable directly to the mobile power plant and charge it with solar energy. The Anderson plug adapter cable has an Anderson plug for the solar modules at both ends. Thanks to the plug and play principle, connecting two modules in series is simple and straightforward.

The complete solar systems from Offgridtec (MPN 014535) are an ideal way to produce a portion of your required household electricity yourself and significantly reduce your overall expenditure on electricity. In addition to a solar module and matching micro inverter, the systems contain everything you need to connect to the household power grid and, if required, to mount on the balcony railing or roof. The set is designed for mounting the modules side by side. Our support team is on hand to provide advice and assistance for customised module installation options. How does a solar system work? The compact Offgridtec solar system consists of a solar module and the matching Hoymiles micro inverter for feeding into the household power grid. Ideally, the inverter is attached directly to the substructure of the solar module and connected to the solar module using the solar plug connector. The AC cable is connected via the Betteri connection of the inverter and routed directly to the appropriate socket. Here you can choose between connection to the standard Schuko socket or to a Wieland feed-in socket, which is included in the scope of delivery when selected. No special settings are required to utilise the solar power generated in the domestic power grid. If electricity is already available from local sources, the appliances in the household use this first and then supplement with mains power as required. The complete solar system includes: 4x Luxen Solar 430W Full Black Solar module Luxneri Series 5 1x Hoymiles HM-1500 Microinverter 1x Connection cable Betteri BC01 socket to Schuko socket (length selectable 5m - 10m - 15m) 4x 3m 6mm² MC-4 connection cable plug/socket extension Or 1x Connection cable micro inverter with Betteri BC01 socket to earthed socket (length selectable 5m - 10m - 15m) Optionally selectable: Installation package for balcony railings - flat roof - plain tile roof - tiled roof - corrugated hernite and sheet metal roof (the respective sets contain 1.25 m long profile rails suitable for the solar system) Luxen 430W Luxneri Series 5 (Full Black) - Efficiency of 22% The monocrystalline and bifacial 430W Series N5 solar module from Luxen Solar impresses with a combination of different technologies, such as N-TOPCon cell technology and a 108 half-cell layout. SMBB half-cut cell technology was also used during production to increase performance. The state-of-the-art solar module represents the pinnacle of solar technology, offering impressive power output and low LCOE. The elegant full-black design makes it a good choice when it comes to finding a solar cell for rooftop installations on residential buildings or for balcony power plants and many other applications. Properties Glass-glass module N-TOPCon cell technology SMBB Half-Cut cell technology Low BOS & LCOE Bifacial cell module technology Excellent anti-PID and low LID performance 3 bypass diodes 30-year performance guarantee and 15-year product guarantee High cell efficiency of over 22% Half-cell technology In half-cell technology ("half-cut"), conventional silicon cells are cut in half using a laser. The resulting halves are then connected centrally in parallel, which leads to increased output of the solar module by reducing resistance losses. Bifacial cells Bifacial means two-faced. And the name says it all: the Luxen Solar 430W N5 module is also equipped with solar cells on the back, which means it can absorb sunlight even better and increases the efficiency of the overall module. Technical data Maximum power: 430W Module voltage (Vmp): 32.04V max. current (Imp): 13.42A open circuit voltage (Voc): 38.96V short-circuit current (Isc): 14.13A Module efficiency: 22.02% Dimensions: 1722 x 1134 x 30 mm Operating temperature range: -40°C to +85°C Cells: 108 (6x18) Max. operating voltage: 1500V DC Weight: 23.5kg Hoymiles HM-1500 Microinverter Module inverter The HM-1500 from Hoymiles is the perfect microinverter for your solar system and is suitable for solar power production with a solar panel up to 470 watts peak power. As with all other Hoymiles microinverters, it is suitable for long operating hours and wide PV module applications, as its start-up is very low (only 22V) and the DC input range of the operating voltage (16-60V) is extremely wide. The Hoymiles micro inverter converts the solar power generated by your photovoltaic system in line with the AC grid and feeds it directly into the utility grid. Recommended module power: up to 470W Maximum input voltage: 60V Maximum input current: 4*11.5A Rated output power: 1500VA Battery voltage range: 16~60V Dimensions (WxHxD): 280 x 176 x 33mm Weight: 3.75kg (including 2.06m AC cable) Optional monitoring of your system is only possible with a data transmission unit (DTU). Here you have the choice between the DTU Lite and the DTU Pro (available soon in the shop). Connection set For the connection cable, you have the option of choosing between a connection for a normal earthed socket or a Wieland feed-in socket. If you choose the latter, the complete system includes an AC extension cable (length selectable) with a Betteri BC01 plug, suitable for the HM-1500 inverter, at one end and an angled Schuko plug at the other end of the cable. This enables quick and uncomplicated connection to the Schuko sockets (plug type F) commonly used in Germany. If the Wieland variant is selected, the AC cable has an angled Wieland RST20I3S plug at the end of the cable for installation in accordance with current technical regulations (e.g. VDE standard AR-N-4105). The appropriate feed socket is then included in the scope of delivery. With the Wieland plug, the pins are not completely exposed, as with the Schuko plug, which minimises the risk of arcing between pin and socket and therefore the risk of overheating and fire. Optional mounting systems Offgridtec solar systems are available with or without mounting sets. Mounting sets are available for: Balcony railing: with matching C-hooks Flat roof: pitch angle 10° - 60° Plain tile roof: with plain tile roof hooks Tiled roof: with 3-way adjustable roof hooks Corrugated hernite and sheet metal roof: with stainless steel hanger bolts Solar installations in Germany There is currently no law or ordinance in Germany that regulates the generation of solar power for purely domestic use. The maximum limit of 600W AC PV power is a reserve value which, according to the current VDE standard, can be fed into an existing socket circuit in a house without overloading it. Nothing is described for independent circuits without additional load. Every electrical installation should be VDE-compliant. However, the operation of such a solar system via the standard earthed socket is not prohibited. Registration with the Federal Network Agency is mandatory. However, there are as yet no known cases of fines for failure to register such solar systems, nor any insurmountable problems with grid operators. Compliance with and implementation of standards and obligations is the responsibility of the system operator. A great deal of technical and legal information can already be found on relevant websites. Do you have further questions about solar energy systems and how they work? Contact us, we will be happy to help you.

The basicPremium-L 200w Solaranlage 12v 24v from Offgridtec (mpn 4-01-002635), is based on a high-quality, monocrystalline 200 wp solar module and the convenient pwm-12/24-30a charge controller with LCD display. The basicPremium series also comes with a matching 8m solar connection cable (solar module to charge controller) and 1.5m battery connection cable - each from the Pro-Connect series. The average daily yield in the period from March to October is about 800 wh*. The solar power of the system can be easily increased by several modules later if your needs increase. The system offers all basic components needed to charge your battery with self-produced solar power. This combination makes it the perfect base for a variety of possible solar applications. High quality basic set for various applications Offgridtec Solar sets of the basicPremium series consist of basic components that every self-sufficient solar power system needs, regardless of whether the system is to be used on a garden shed, the garage or in mobile applications. We constantly focus on high quality of all delivered components to ensure reliability and a long life expectancy of the system. Our 100w solar module is equipped with the best monocrystalline cells and is produced and tested using the latest manufacturing technology. The remaining components of the set also follow this quality standard: The plug & play connection cables "made in Germany" are designed to keep the installation effort as low as possible without compromising on the connection quality. The pwm-12/24-30a Pro charge controller, with its convenient display and up-to-date charging algorithms, ensures easy operation of the system and perfect charging of your batteries. The basicPremium family is a mature product that has proven itself thousands of times in practice and offers the ideal starting point for a wide range of applications. applications Solaranlage 12v or 24v dc power supply in garden sheds, allotments and similar objects self-sufficient systems for outdoor lighting applications self-sufficient monitoring and communication systems or weather stations charging of smartphones, tablets or other devices with 12v / 5v dc power supply Performance parameters at a glance average daily yield: 800 wh Expandability of solar power by using the same panel to max. 300 wp (at 24v = 700 wp) Available power outputs: 5v dc and 12v dc at the charge controller (230v only with optional voltage converter) Components of the basicPremium-L 200w Solaranlage 12v 24v 2 x Offgridtec 100w V2 Solarpanel 23V black frame Rated power: 200 wp, part number: 3-01-018385 Operating voltage (Vmp) 23,9 v, operating current (Imp) 4,2 a equipped with high quality monocrystalline solar cells minimized power loss during shading due to integrated bypass diode black frame Solar connector, dimensions (WxLxH): 925 x 560 x 35 mm, weight: 6,22 Kg 1 x PwM-12/24-30 Pro solar controller 12v/24v max. charging current 30 a, max. PV power at 12v / 24v system: 390 w / 780 w modern, 3-stage PwM charge control for gentle and efficient charging of your battery(ies) 3 battery types adjustable: agm, gel, and liquid lead acid intuitive operation via 2 buttons directly on the device large LCD display with numerous display options, including kwh meter 2 usb ports with a maximum output power of 2.4a Load output with numerous configuration options, e.g. for light control Temperature compensated battery charging (optional temperature sensor required) 1x 8m 2x6mm² solar connection cable controller/solar module TwIN cable, plug & play - ready for immediate use Solar connector on solar module side, ferrules on charge controller side highest quality solar cable: TwIN cable wire cross section: 2x6mm², length: 8m 1x 1,5 2x6mm² 30 a battery connection cable controller/battery (Offgridtec) Plug & Play - immediately ready for use wire cross section: 2x6mm², length: 1,5m including flat fuse holder with built-in 30 a aTO fuse ferrules on charge controller side, m8 ring terminals on battery side incl. battery pole terminals for connection to round pole terminals 1x Offgridtec branching sockets Y-connector (pair) Flexible and very easy to install The system is very easy to install, even by people who have little experience with solar technology. The cables are all delivered plug & play, ready for connection. You only need to connect the components together and the power production can begin. Expandable, customizable like every system from Offgridtec, the basicPremium-S can also be individually adapted and modified to your requirements. Our technical sales department is looking forward to your inquiry. Please contact customer service for any costs that may be incurred. Scope of delivery: 1x Offgridtec 4-01-002635 basicPremium-L 200w 12v 24v Solaranlage 1x instruction manual including all components listed above

The basicPremium-L 100w Solaranlage 12v from Offgridtec (mpn 4-01-002600), is based on a high-quality, monocrystalline 100 wp solar module and the convenient pwm-12/24-20a charge controller with LCD display. The basicPremium series also comes with a matching 8m solar connection cable (solar module to charge controller) and 1.5m battery connection cable - each from the Pro-Connect series. The average daily yield in the period from March to October is about 400 wh*. The solar power of the system can be easily increased by several modules later if your needs increase. The system offers all basic components needed to charge your battery with self-produced solar power. This combination makes it the perfect base for a variety of possible solar applications. High-quality basic set for a wide range of applications Offgridtec Solar sets of the basicPremium series consist of basic components that every self-sufficient solar power system needs, regardless of whether the system is to be used on a garden shed, the garage or in mobile applications. We constantly focus on high quality of all delivered components to ensure reliability and a long life expectancy of the system. Our 100w solar module is equipped with the best monocrystalline cells and is produced and tested using the latest manufacturing technology. The remaining components of the set also follow this quality standard: The plug & play connection cables "made in Germany" are designed to keep the installation effort as low as possible without compromising on the connection quality. The pwm-12/24-20a Pro charge controller, with its convenient display and up-to-date charging algorithms, ensures easy operation of the system and perfect charging of your batteries. The basicPremium family is a mature product that has proven itself thousands of times in practice and offers the ideal starting point for a wide range of applications. applications Solaranlage 12v dc power supply in garden sheds, allotments and similar objects self-sufficient systems for outdoor lighting applications self-sufficient monitoring and communication systems or weather stations charging of smartphones, tablets or other devices with 12v / 5v dc power supply Performance parameters at a glance average daily yield: 400 wh Expandability of solar power by using the same panel to max. 200 wp Available power outputs: 5v dc and 12v dc at the charge controller (230v only with optional voltage converter) Components of the basicPremium-L 100w Solaranlage 12v 1 x Offgridtec MONO 100W V2 Solarpanel 23V Black Frame Rated power: 100 wp, part number: 3-01-018385 Operating voltage (Vmp) 23,9 v, operating current (Imp) 4,2 a equipped with high quality monocrystalline cells minimized power loss during shading due to integrated bypass diode black frame MC4 connector, dimensions (WxLxH): 925 x 560 x 35 mm, weight: 6,22 Kg 1 x PwM-12/24-20 Pro solar controller 12v/24v max. charging current 20 a, max. PV power at 12v: 260 w modern, 3-stage PwM charge control for gentle and efficient charging of your battery(ies) 3 battery types adjustable: agm, gel, and liquid lead acid intuitive operation via 2 buttons directly on the device large LCD display with numerous display options, including kwh meter 2 usb ports with a maximum output power of 2.4a Load output with numerous configuration options, e.g. for light control Temperature compensated battery charging (optional temperature sensor required) 1x 8m 2x6mm² solar connection cable controller/solar module TwIN cable, Plug & Play - ready for immediate use MC4 connector on solar module side, ferrules on charge controller side highest quality solar cable: TwIN cable wire cross section: 2x6mm², length: 8m 1x 1,5 2x6mm² 30 a battery connection cable controller/battery (Offgridtec) Plug & Play - immediately ready for use wire cross section: 2x6mm², length: 1,5m including flat fuse holder with built-in 30 a aTO fuse ferrules on charge controller side, m8 ring terminals on battery side incl. battery pole terminals for connection to round pole terminals Flexible and very easy to install The system is very easy to install, even by people who have little experience with solar technology. The cables are all delivered plug & play, ready for connection. You only need to connect the components together and the power production can begin. Expandable, customizable like every system from Offgridtec, the basicPremium-S can also be individually adapted and modified to your requirements. Our technical sales department is looking forward to your inquiry. Please contact customer service for any costs that may be incurred. Scope of delivery: 1x Offgridtec 4-01-002600 basicPremium-L 100w 12v Solaranlage 1x instruction manual including all components listed above

The basicPremium-L 300w Solaranlage 12v 24v from Offgridtec (mpn 4-01-002655), is based on a high quality monocrystalline 300 wp solar module and the convenient pwm-12/24-45a charge controller with LCD display. The basicPremium series also comes with a matching 8m solar connection cable (solar module to charge controller) and 1.5m battery connection cable. The average daily yield in the period from March to October is about 1200 wh*. The solar power of the system can be easily increased by several modules later if your needs increase. The system offers all basic components needed to charge your battery with self-produced solar power. This combination makes it the perfect base for a variety of possible solar applications. High-quality basic set for a wide range of applications Offgridtec Solar sets of the basicPremium series consist of basic components that every self-sufficient solar power system needs, regardless of whether the system is to be used on a garden shed, the garage or in mobile applications. We constantly focus on high quality of all delivered components to ensure reliability and a long life expectancy of the system. Our 100w solar module is equipped with the best monocrystalline cells and is produced and tested using the latest manufacturing technology. The remaining components of the set also follow this quality standard: The plug & play connection cables "made in Germany" are designed to keep the installation effort as low as possible without compromising on the connection quality. The pwm-12/24-45a Pro charge controller, with its convenient display and up-to-date charging algorithms, ensures good operability of the system and perfect charging of your batteries. The basicPremium family is a mature product that has proven itself thousands of times in practice and offers the ideal starting point for a wide range of applications. applications Solaranlage 12v or 24v dc power supply in garden sheds, allotments and similar objects self-sufficient systems for outdoor lighting applications self-sufficient monitoring and communication systems or weather stations charging of smartphones, tablets or other devices with 12v / 5v dc power supply Components of the basicPremium-L 300w Solaranlage 12v 24v 3 x Offgridtec 100w V2 Solarpanel 23V black frame Rated power: 300 wp, part number: 3-01-018385 Operating voltage (Vmp) 23,9 v, operating current (Imp) 4,2 a minimized power drop in case of shading due to integrated bypass diode black frame Solar connector, dimensions (WxLxH): 925 x 560 x 35 mm, weight: 6,22 Kg 1 x pwm-12/24-45 Pro solar controller 12v/24v max. charging current 45 a, max. PV power at 12v / 24v system: 590 w / 1180 w modern, 3-stage PwM charge control for gentle and efficient charging of your battery(ies) 3 battery types adjustable: agm, gel, and liquid lead acid intuitive operation via 2 buttons directly on the device large LCD display with numerous display options, including kwh meter 2 usb ports with a maximum output power of 2,4a Load output with numerous configuration options, e.g. for light control Temperature compensated battery charging (optional temperature sensor required) 1x 8m 2x6mm² solar connection cable controller/solar module TwIN cable, plug & play - ready for immediate use Solar connector on solar module side, ferrules on charge controller side highest quality solar cable: TwIN cable wire cross section: 2x6mm², length: 8m 1x 1,5m 10mm² 50 a battery connection cable controller/battery (Offgridtec) Plug & Play - immediately ready for use wire cross section: 10mm², length: 1,5m including MIDI fuse holder and with 50a MIDI fuse ferrules on charge controller side, m8 ring terminals on battery side incl. battery terminals for connection to round terminals 2x junction boxes and 4x solar connection cables for connecting the solar modules Flexible and very easy to install The system is very easy to install, even by people who have little experience with solar technology. The cables are all delivered plug & play, ready for connection. You only need to connect the components together and the power production can begin. Expandable, customizable like every system from Offgridtec, the basicPremium-S can also be individually adapted and modified to your requirements. Our technical sales department is looking forward to your inquiry. Please contact customer service for any costs that may be incurred. Scope of delivery: 1x Offgridtec 4-01-002655 basicPremium-L 300w 12v 24v Solaranlage 1x instruction manual including all components listed above

The Offgridtec SolarFlow balcony power station (MPN 019805) withZendure Storage presents an excellent solution to generate a part of your required household electricity yourself and thus significantly reduce the total expenditure for electricity. This system is equipped with 4 powerful 480w glass-glass solar modules, the compact hms-1000-2t micro inverter and the Smart pv Hub 2000. The included hms connection cable facilitates effortless installation of all components thanks to its simple plug-and-play principle. In addition, you can choose between 1 to 4 ab1000 or ab2000 batteries to store the solar power generated. A total capacity of up to 7,680wh is possible. The batteries ensure efficient energy storage, allowing solar power to be used even when there is little sunlight or at night. The balcony power station contains: 4x Luxen Solar 480w Mono Bifacial Glass-Glass Solar Module Black Frame 1x Hoymiles hms-1000-2t micro inverter Zendure Solarflow expansion battery (optionally selectable) 1-4x from1000 960wh Add on LiFePO4 1-4x from2000 1920wh Add on LiFePO4 1x Zendure SolarFlow Smart pv Hub 2000 MPPT 1x Hoymiles hms connection cable Field Connector Plug&Play 5m 2x Offgridtec 2-way branch sockets Y-connector 2x connection cable mc4 to mc4 6mm² 5m Luxen Solar 480w Mono Bifacial Glass-Glass Solar Panel Black Frame The monocrystalline and bifacial 480w Black Frame Series n5 solar module from Luxen Solarsolar module impresses with a combination of different technologies, such as N-TOPCon cell technology and a 120 half-cell layout. The smbb half-cut cell technology was also used during production to increase performance. The state-of-the-art solar module represents the pinnacle of solar technology, offering impressive power output and low LCOE. Glass-glass module Low bos & LCOE Bifacial cell module technology excellent anti-PID and low lid performance 3 bypass diodes Technical data maximum power: 480w Module voltage (Vmp): 35.69V max. current (Imp): 13.45A Open circuit voltage (Voc): 43.36V Short-circuit current (Isc): 14.16A Module efficiency: 22.16% hms-1000-2t The hms-1000-2t fromHoymiles is the perfect micro inverter for your balcony power plant. The compact lightweight (only 3.2 kg) is suitable for solar power production with up to two solar panels with an output of 400 to 670+ w each. Minimization of the effects of e.g. shading, dust or ageing through MPPT High-quality energy generation with high MPPT accuracy Peak efficiency of 96.5% Technical data MPPT voltage range: 16-60V Switch-on voltage: 22V Maximum input voltage: 65V CEC peak efficiency: 96.50% Zendure Solarflow expansion batteries Technical data from 1000 Capacity: 960wh (20Ah / 48V) Battery type: LiFePO4 Max. Extension capacity: 4 x 960wh = 3840 wh Protection class: IP65 Weight: 11.5 kg Dimensions: 350 x 200 x 186.5 mm Technical data ab2000 Capacity: 1920wh (40Ah / 48V) Battery type: LiFePO4 Max. Extension capacity: 4 x 1920wh = 7680 wh Protection class: IP65 Weight: 25 kg Dimensions: 450 x 280 x 420mm Zendure SolarFlow Smart pv Hub 2000 MPPT Technical data Recommended input power pv modules: 1200 w (per tracker) Max. Input voltage: 60 V MPPT voltage range: 16-60 V MPPT voltage range at full power: 35-60 V Number of mppt: 2 Max. Input current: 2x26 A hms connection cable Field Connector Plug&Play The Hoymiles hms Plug&Play connection cable is specially designed for use in pv systems with just one hms inverter. It consists of a field connector, an ac cable and an ac plug. The field connector is connected to the inverter and the plug to the household socket. Cable type: pv07ac-F Cable length: 5m Rated voltage: 250V Rated current: 12A Balcony power stations in Germany There is currently no law or regulation in Germany governing the generation of solar power for purely domestic use. The maximum limit of 600w ac pv power is a reserve value which, according to the current VDE standard, can be fed into an existing socket circuit of a house without overloading it. Nothing is described for independent circuits without additional load. Every electrical installation should be VDE-compliant. However, operating a balcony power station via the standard earthed socket is not prohibited. Registration with the Federal Network Agency is mandatory. However, there are no known cases of fines for non-registration of balcony power stations or insurmountable problems with network operators. Compliance with and implementation of standards and obligations is the responsibility of the system operator. A great deal of technical and legal information can already be found on relevant websites.

The Offgridtec Balcony power station (MPN 019800) with Zendure SolarFlow storage system presents an excellent solution for generating part of your required household electricity yourself and thus significantly reducing your overall expenditure on electricity. The system is equipped with 4 powerful 430w glass-glass solar modules, the compact hms-800w-2t micro inverter and the Smart pv Hub 2000. The included hms connection cable facilitates effortless installation of all components thanks to its simple plug-and-play principle. In addition, you can choose between 1 to 4 ab1000 or ab2000 batteries from Zendure to store the solar power generated. A total capacity of up to 7,680wh is possible. The batteries ensure efficient energy storage, allowing solar power to be used even when there is little sunlight or at night. The balcony power station contains: 4x Luxen Solar 430w Mono Bifacial Glass-Glass Solar Module Full Black 1x Hoymiles hms-800w-2t micro inverter Zendure Solarflow expansion battery (optionally selectable) 1-4x from1000 960wh Add on LiFePO4 1-4x from2000 1920wh Add on LiFePO4 1x Zendure SolarFlow Smart pv Hub 2000 MPPT 1x Hoymiles hms connection cable Field Connector Plug&Play 5m 2x Offgridtec 2-way branch sockets Y-connector 2x connection cable mc4 to mc4 6mm² 5m Luxen Solar 430w Mono Bifacial Glass-Glass Solar Panel Full Black The monocrystalline and bifacial 430w Full Black solar module of the Series n5 from Luxen Solar solar module impresses with a combination of different technologies, such as N-TOPCon cell technology and a 108 half-cell layout. The smbb half-cut cell technology was also used during production to increase performance. The state-of-the-art solar module represents the pinnacle of solar technology, offering impressive power output and low LCOE. Glass-glass module Low bos & LCOE Bifacial cell module technology excellent anti-PID and low lid performance 3 bypass diodes Technical data maximum power: 430w Module voltage (Vmp): 32.04V max. current (Imp): 13.42A Open circuit voltage (Voc): 38.96V Short-circuit current (Isc): 14.13A Module efficiency: 22.02% hms-800w-2t The hms-800w-2t fromHoymiles is the perfect micro inverter for your balcony power station. In addition to the integrated wiFi module in Industry+ quality to be mentioned here, the compact lightweight (only 3.2kg) is ideal for solar power production with up to two solar panels with an output of 320 to 540+w each. Integrated wiFi module High-quality energy generation with high MPPT accuracy Peak efficiency of 96.7% Technical data MPPT voltage range: 16-60V Switch-on voltage: 22V Maximum input voltage: 65V CEC peak efficiency: 96.70% Number of MPPTs: 2 Zendure Solarflow expansion batteries Technical data from 1000 Capacity: 960wh (20Ah / 48V) Battery type: LiFePO4 Max. Extension capacity: 4 x 960wh = 3840 wh Protection class: IP65 Weight: 11.5 kg Dimensions: 350 x 200 x 186.5 mm Technical data ab2000 Capacity: 1920wh (40Ah / 48V) Battery type: LiFePO4 Max. Extension capacity: 4 x 1920wh = 7680 wh Protection class: IP65 Weight: 25 kg Dimensions: 450 x 280 x 420mm Zendure SolarFlow Smart pv Hub 2000 MPPT Technical data Recommended input power pv modules: 1200 w (per tracker) Max. Input voltage: 60 V MPPT voltage range: 16-60 V MPPT voltage range at full power: 35-60 V Number of mppt: 2 Max. Input current: 2x26 A hms connection cable Field Connector Plug&Play The Hoymiles hms Plug&Play connection cable is specially designed for use in pv systems with just one hms inverter. It consists of a field connector, an ac cable and an ac plug. The field connector is connected to the inverter and the plug to the household socket. Cable type: pv07ac-F Cable length: 5m Rated voltage: 250V Rated current: 12A Balcony power stations in Germany There is currently no law or regulation in Germany governing the generation of solar power for purely domestic use. The maximum limit of 600w ac pv power is a reserve value which, according to the current VDE standard, can be fed into an existing socket circuit of a house without overloading it. Nothing is described for independent circuits without additional load. Every electrical installation should be VDE-compliant. However, operating a balcony power station via the standard earthed socket is not prohibited. Registration with the Federal Network Agency is mandatory. However, there are no known cases of fines for non-registration of balcony power stations or insurmountable problems with network operators. Compliance with and implementation of standards and obligations is the responsibility of the system operator. A great deal of technical and legal information can already be found on relevant websites.

The OffgridtecsolarFlow balcony power station (MPN 019810) with Zendure Storage presents an excellent solution to generate a part of your required household electricity yourself and thus significantly reduce the total expenditure for electricity. This system is equipped with 4 powerful 480w glass-glass solar modules, the compact hms-800w-2t micro inverter and the Smart pv Hub 2000. The included hms connection cable facilitates effortless installation of all components thanks to its simple plug-and-play principle. In addition, you can choose between 1 to 4 ab1000 or ab2000 batteries to store the solar power generated. A total capacity of up to 7,680wh is possible. The batteries ensure efficient energy storage, allowing solar power to be used even when there is little sunlight or at night. The balcony power station contains: 4x Luxen Solar 480w Mono Bifacial Glass-Glass Solar Module Black Frame 1x Hoymiles hms-800w-2t micro inverter Zendure Solarflow expansion battery (optionally selectable) 1-4x from1000 960wh Add on LiFePO4 1-4x from2000 1920wh Add on LiFePO4 1x Zendure SolarFlow Smart pv Hub 2000 MPPT 1x Hoymiles hms connection cable Field Connector Plug&Play 5m 2x Offgridtec 2-way branch sockets Y-connector 2x connection cable mc4 to mc4 6mm² 5m Luxen Solar 480w Mono Bifacial Glass-Glass Solar Panel Black Frame The monocrystalline and bifacial 480w Black Frame Series n5 solar module from Luxen Solarsolar module impresses with a combination of different technologies, such as N-TOPCon cell technology and a 120 half-cell layout. The smbb half-cut cell technology was also used during production to increase performance. The state-of-the-art solar module represents the pinnacle of solar technology, offering impressive power output and low LCOE. Glass-glass module Low bos & LCOE Bifacial cell module technology excellent anti-PID and low lid performance 3 bypass diodes Technical data maximum power: 480w Module voltage (Vmp): 35.69V max. current (Imp): 13.45A Open circuit voltage (Voc): 43.36V Short-circuit current (Isc): 14.16A Module efficiency: 22.16% hms-800w-2t The hms-800w-2t fromHoymiles is the perfect micro inverter for your balcony power station. In addition to the integrated wiFi module in Industry+ quality to be mentioned here, the compact lightweight (only 3.2kg) is ideal for solar power production with up to two solar panels with an output of 320 to 540+w each. Integrated wiFi module High-quality energy generation with high MPPT accuracy Peak efficiency of 96.7% Technical data MPPT voltage range: 16-60V Switch-on voltage: 22V Maximum input voltage: 65V CEC peak efficiency: 96.70% Number of MPPTs: 2 Zendure Solarflow expansion batteries Technical data from 1000 Capacity: 960wh (20Ah / 48V) Battery type: LiFePO4 Max. Extension capacity: 4 x 960wh = 3840 wh Protection class: IP65 Weight: 11.5 kg Dimensions: 350 x 200 x 186.5 mm Technical data ab2000 Capacity: 1920wh (40Ah / 48V) Battery type: LiFePO4 Max. Extension capacity: 4 x 1920wh = 7680 wh Protection class: IP65 Weight: 25 kg Dimensions: 450 x 280 x 420mm Zendure SolarFlow Smart pv Hub 2000 MPPT Technical data Recommended input power pv modules: 1200 w (per tracker) Max. Input voltage: 60 V MPPT voltage range: 16-60 V MPPT voltage range at full power: 35-60 V Number of mppt: 2 Max. Input current: 2x26 A hms connection cable Field Connector Plug&Play The Hoymiles hms Plug&Play connection cable is specially designed for use in pv systems with just one hms inverter. It consists of a field connector, an ac cable and an ac plug. The field connector is connected to the inverter and the plug to the household socket. Cable type: pv07ac-F Cable length: 5m Rated voltage: 250V Rated current: 12A Balcony power stations in Germany There is currently no law or regulation in Germany governing the generation of solar power for purely domestic use. The maximum limit of 600w ac pv power is a reserve value which, according to the current VDE standard, can be fed into an existing socket circuit of a house without overloading it. Nothing is described for independent circuits without additional load. Every electrical installation should be VDE-compliant. However, operating a balcony power station via the standard earthed socket is not prohibited. Registration with the Federal Network Agency is mandatory. However, there are no known cases of fines for non-registration of balcony power stations or insurmountable problems with network operators. Compliance with and implementation of standards and obligations is the responsibility of the system operator. A great deal of technical and legal information can already be found on relevant websites.

The solarasystems from Offgridtec systems offer a clever solution for generating part of the electricity required for the household and thus achieving considerable savings on the total cost of electricity consumption. The system includes four solar modules, a Hoymiles Micro inverter including DTU control unit and an AC connection cable that connects the inverter to a socket. The modules are designed so that they can be installed directly next to each other. In addition, you can choose between 1 to 4 ab1000 or ab2000 batteries to store the solar power generated. A total capacity of up to 7,680wh is possible. These batteries enable efficient energy storage, ensuring the use of solar power even when there is little sunlight or during the night. how does a solarasystem for feeding into the household grid work? The Offgridtec solara system consists of four solar modules and a matching Hoymiles micro inverter. This is attached directly to the substructure of the solar module and connected via the solar connector. The AC cable is connected via the inverter's Betteri connection and routed to the appropriate socket. The Zendure smart plug included in the scope of delivery can be plugged into the Schuko socket to enable smart energy monitoring. The extension batteries are used to store surplus solar energy and retrieve it when needed. The complete solar system contains: 4x Trina solar vertex s TsM-NEG9R.28 430w dual glass solar module 1-4x Zendure solarFlow ab1000 Extension battery 960wh Add-On LiFePO4 or 1-4x Zendure solarFlow ab2000 extension battery 1920wh 1x Zendure solarFlow smart pv Hub 1200w MPPT 1x Hoymiles hm-1500 inverter 1x Hoymiles DTU-wLite data transmission and control unit 1x 5m connection cable Betteri bc01 socket to earthed socket outlet 1x Betteri End cap for bc01 socket ip67 Female 2x connection cable mc4 to mc4 6mm² 2m red/black Trina solar vertex s 430w dual glass solar panel The vertex s TsM-NEG9R.28 fromTrina solaris a 430w solar module with monocrystalline cells and dual glass technology. The multi-busbar technology ensures increased absorption, lower series resistance, improved current dissipation and increased reliability. The module is certified for use under extreme wind and snow loads of 4000 - 6000 Pa (tested loads). its highly transparent glass is 3.2 mm thick and has an anti-reflective coating. Multi-busbar technology Dual-glass design very low degradation Manufacturer product warranty: 15 years Incl. connection cable Technical data Power (Pmax): 430 w voltage (vmp): 43.2 v Max. current (Imp): 9.96 A Open circuit voltage (voc): 51.4 V Short-circuit current (Isc): 10.60 A Max. system voltage: 1500v DC Cell efficiency: 21.5% Dimensions: 1762 x 1134 x 30 mm Weight: 21.1 kg protection class junction box: IP68 Communication: mc4 ev02 / Ts4 Zendure solarFlow extension battery Total capacity of 3,840wh possible (modular expansion) IP65 waterproof protection monitoring and control via app possible 10-year manufacturer's warranty Simple integration TÜv Rheinland certified (id 1111272000) Technical data from 1000 Capacity: 960wh (20Ah / 48v) Max. Extension capacity: 4 x 960wh = 3840 wh Battery type: LiFePO4 Weight: 11.5 kg Dimensions: 350 x 200 x 186.5 mm Technical data ab2000 Capacity: 1920wh (40Ah / 48v) Max. Extension capacity: 4 x 1920wh = 7680 wh Battery type: LiFePO4 Weight: 25 kg Dimensions: 450 x 280 x 420mm Hoymiles hm-1500 module inverter The Hoymiles hm-1500 is a compact micro inverter ideal for solarasystems. With a 2.06 m AC cable, it is suitable for up to four solar panels with an output of 470 w each. Hoymiles micro inverters are characterized by their long service life and wide range of applications. With a low start-up voltage of just 22 v and a wide DC input voltage range of 16-60 v, it is extremely versatile. Recommended module power: up to 470w Max. Input voltage: 60v Max. Input current: 4*11.5A Rated output power: 1500vA Operating voltage range: 16~60v Dimensions (WxHxD): 280 x 176 x 33mm Weight. 3,75kg Hoymiles DTU-wLite The Hoymiles Gateway DTU-wLite is a wireless data transmission unit that collects information from microinverters and sends it via wifi to the Hoymiles monitoring system s-Miles Cloud. With the DTU-wLite you can read data and alarms at module level, remotely monitor and maintain the microinverter system. It supports up to 4 modules and is ideal for small pv systems. Note:dTU-wLite is connected to a domestic power socket via a 5v UsB power supply unit. The power supply unit is not included in the scope of delivery. It works with almost all UsB power supply units that can deliver at least 1a power. The s-Miles account can be created directly by the end user. The instructions from Hoymiles can be found in the download area of this article. socket connection The solar system set contains a 5m long AC extension cable with Betteri bc01 plug, suitable for the hm-1500 inverter, at one end and an angled schuko plug at the other end of the cable. This enables quick and uncomplicated connection to the standard German Schuko sockets (plug type f).

The backup systems from Offgridtec are ideal for emergency power supply or for expanding an existing solar system. In addition to lithium-ion batteries from Pylontech, the systems include a matching MultiPlus-II inverter and a Cerbo gx from Victron Energy for system monitoring. This allows you to secure your energy supply even if there is a power failure. Thanks to the UPS function, the MultiPlus remains switched on even in the event of a mains failure and takes over the supply of the connected loads. The switchover happens so quickly (in less than 20 milliseconds) that uninterrupted operation of computers and other electronic devices can be guaranteed. Areas of application of the Offgridtec backup kit: Emergency power supply Off-grid solar systems (stand-alone systems) Retrofitting of existing PV systems Grid-connected power supply UPS systems What does the Offgridtec backup system contain? Pylontech us2000c 2.4kWh LiFePO4 battery (2x or 4x depending on selection) 1x Victron MultiPlus-II 48/3000/35-32 230v device combination 1x Victron Lynx Distributor 1x Victron Cerbo gx control panel 1x Victron gx Touch 50 display panel for Cerbo gx 1x 1,8m VE.Can to Can-Bus bms type A cable 1x 3m Victron rj45 utp cable 1x 1m Offgridtec battery cable 50mm² M8 eyelets 1x 125a 70v mega fuse 1x Pylontech battery connection cable set The Multiplus device combination is pre-configured to fit the Pylontech batteries. The storage solution - Pylontech us2000c batteries The us2000c storage is a lithium battery of the latest generation. It has been specially designed to meet the high demands placed on backup storage. Thanks to state-of-the-art technology, the highest level of safety and a long service life are guaranteed, even with regular deep discharge. Extremely cycle resistant - over 6000 cycles at 95% DoD Absolutely intrinsically safe lithium technology High charge and discharge capacity possible Integrated bms Very high storage density - low weight and compact design Absolutely maintenance-free and durable Pre-charge function to protect the ESS system from overvoltage function The electronics core - the Victron Multiplus-II device combination The Multiplus-II is a high-end device combination from Victron Energy, consisting of 48v battery charger, inverter and transfer switch. This combination combines the classic Multiplus components with an external current sensor and integrated anti-islanding function. This extends the PowerControl and PowerAssist functions to 50a and extends the potential range of use to energy storage system applications. The Multiplus can therefore be ideally used as a backup device in grid-connected and grid-independent power supply systems. 3000W non-linear load power - 2400w continuous load - 6000w peak power for 48v battery voltage 32A transfer switch 35A battery charger Output voltage: 230 vac, frequency: 50 Hz max. efficiency: 95% Protection class: IP22 System monitoring with the Victron Cerbo gx and gx Toch display Easily control and monitor your system with the Cerbo gx communication center. The flexible connectivity options maximize your system performance. Control of your system is possible regardless of location thanks to the Cerbo gx. With the gx Touch 50 display, you always have all the parameters of your system in view and can make changes easily and quickly.

Extremely versatile complete package The Offgridtec® HomePremium series is a true all-rounder at an unbeatable price-performance ratio. As well as being used as a usv backup solution with a choice between mains and battery priority, this PV system can also be used as a self-consumption system. There are virtually no limits to the performance of this Solarasystem - depending on personal requirements and on request, extensions are possible, both on the module and battery side. if a higher output power is required on the inverter, additional identical devices can also be connected here to increase performance. In addition to the power electronics, the storage system and the solar modules, all components required for the connection are also included in the scope of delivery, with the exception of the solar module holder, which must be ordered separately. all other components are plug and play - this means no annoying plug installation or the like - connect and you're done. Depending on your choice, the system is supplied with or without an electricity meter. Parts list - what's inside 10x Luxen Solar 430w Full Black Solar Panel Luxneri Series 5 victron Energy 48/5000 MultiPlus-II inverter mpn PMP482505010 victron Energy mppt SmartSolar charge controller 250/70-Tr victron Energy Lynx Distributor for dc distribution and fuse protection 2x 3.5kwh Pylontech us3000c LiFePo4 storage batteries inverter connection cable for connecting the Pylontech batteries to the MultiPlus 48/5000 (2m) vE.Can to CaN-Bus bms type a cable 1.8m for connecting the Cerbo gx to the storage system 3m victron rj45 utp cable for connecting the MultiPlus to the Cerbo gx Cerbo gx + gx Touch 50 from victron Energy - the communication center of your system 1m battery cable 25mm² m8 terminal to screw terminal connection for connecting the charge controller to the battery 1m battery cable 50mm² m8 eyelets on both sides for connecting Multiplus and Lynx Distributor 10m Offgridtec® Professional connection cable 6mm² solar module to charge controller for the connection between solar modules and charge controller Solar connector branch sockets (pair) - for parallel connection of two strings of modules 2x 5m 6mm² solar connector connection cable plug/socket extension for connecting the two module strings with the solar plug branch sockets victron 3m vE.Direct cable connection cable for connecting the charge controller to the Cerbo gx victron 200a 58v/48v MEGa-Fuse fuse for Multiplus Offgridtec 80a 48v MEGa-Fuse fuse for solar charge controller For selection of electricity meter: 1x victron vm-3p75ct Energy Meter 1x victron 5m rj45 utp cable Extended use of your HomePremium system The HomePremium system is supplied either with or without victron electricity meter and cable, whereby the energy meter with connection cable is required to set up an energy storage system (ess). With this electricity meter, you can carry out a grid-parallel installation and monitor your energy consumption or control your energy costs. thanks to phase compensation, you can also operate the 3-phase meter for 1-phase systems. This means that seamless integration of decentralized energy sources and consumers into the existing power grid is no problem. Luxen Solar 430w Full Black solar module The monocrystalline and bifacial 430w Full Black Series n5 solar module fromLuxen Solarsolar module impresses with a combination of different technologies, such as N-TOPCon cell technology and a 108 half-cell layout. The smbb half-cut cell technology was also used during production to increase performance. The state-of-the-art solar module represents the pinnacle of solar technology, offering impressive power output and low LCOE. Glass-glass module N-TOPCon cell technology smbb Half-Cut cell technology Low bos & LCOE Bifacial cell module technology excellent anti-PID and low lid performance 3 bypass diodes 30-year performance guarantee and 15-year product guarantee high cell efficiency of over 22% Technical data maximum power: 430w Module voltage (vmp): 32.04v max. current (imp): 13.42a Open circuit voltage (voc): 38.96v Short-circuit current (Isc): 14.13a dimensions: 1722 x 1134 x 30 mm Operating temperature range: -40°C to +85°C Cells: 108 (6x18) max. operating voltage: 1500v dc Weight: 23,5kg LiFePo4 storage technology from Pylontech The us3000c storage battery from Pylontech is a lithium iron phosphate battery of the latest generation that offers maximum safety and service life. Each module has a battery management system (bms) for comprehensive protection against deep discharge, overcharging and damage caused by high currents or extreme temperatures. Short circuits and reverse polarity are also excluded. Features of the Pylontech us3000c memory modules Extremely cycle-proof - over 6000 cycles at 95% DoD (discharge per cycle) absolutely intrinsically safe due to integrated protective shutdown (bms) High charging and discharging capacity of up to 5kw per module High storage density Low weight and compact design absolutely maintenance-free and easy to install 10-year guarantee The heart of the system - the victron MultiPlus-II 48/5000 The Multiplus-II 48/5000/70-50 from victron Energy combines classic Multiplus components with an external current sensor and integrated anti-islanding function. This extends the PowerControl and Powerassist functions to 100a and enables use in ess applications. PowerControl and Powerassist - increasing grid or generator output Built-in anti-islanding function and connection option for external current sensor (optional) Can be used as a backup device in grid-connected systems vE.Bus interface for parallel and three-phase operation Remote monitoring and system integration Parallel and three-phase operation Approved according to vDE-aR-N 4105 Technical data 5000 w power with non-linear load - 4000 w continuous load - 9000 w peak power For 48 v battery voltage, 50 a transfer switch and 70a battery charger output voltage: 230 vaC, frequency: 50 Hz Max. efficiency: 95% Protection class IP22 Maximum flexibility thanks to two AC outputs The MultiPlus-II offers uninterrupted operation by automatically taking over the supply to consumers in the event of mains failures or interruptions to the shore/generator power. The switchover takes place in less than 20 milliseconds to ensure continuous operation of electronic devices. A second output supplies power only when alternating current is present at the input of the MultiPlus-II. This makes it possible to connect consumers such as a water heater that should not be discharged from the battery. delivery is configured and matched to the components supplied The setting options on the MultiPlus-II are extremely varied, as are its possible applications. We have already made the most important settings for you so that the system, as it is supplied, lives up to the description "plug and play" - the system is therefore ready for immediate use without any further configuration. if you order the selection with an electricity meter, we will set up the system directly as an ess. victron Energy Cerbo gx and gx Touch 50 - the communication center of your system The latest development in system monitoring from the company allows you to control and configure your system with ease. rounded off by the gxC Touch 50 - a waterproof 5 inch touchscreen - you always have an overview of your system parameters. The Cerbo's functions allow you to control and monitor your system perfectly, while maximizing system performance in an unprecedentedly simple way. victron Energy has developed a new system monitor that allows you to easily control and configure your system. The gx Touch 50, a waterproof 5-inch touchscreen, provides a clear overview of your system parameters. The Cerbo module allows you to precisely monitor your system and maximize performance. It is compatible with both solar charge controllers and grid-connected inverters. Mounting material and connection cable are included in the scope of delivery. The Bluetooth function of the gx Touch 50 makes accessing your system even quicker and easier. An optional wall bracket is available. victron Remote portal The victron Remote Portal (vRM) is a free victron Energy Service that allows you to read out your system data remotely and configure the devices accordingly. This means that you always have full control and an overview of all relevant system parameters, even when you are away. The functionality is available online as a demo version and is ideal for getting a first impression - https://vrm.victronenergy.com/landingpage Safety note: Only have this complete system installed and commissioned by a qualified electrician.

The All-In-One complete system from Offgridtec (mpn: 019825) is a 1215wp balcony power plant that offers you an ideal solution for producing part of your required household electricity yourself. The central element is the Zendure aio battery storage system, which consists of a very efficient LiFePO4 battery with 2.4kwh and a perfectly matching pv hub. The set is completed by 3 powerful 405w glass-glass solar modules from Luxen Solara compact hm-1200 micro inverter from Hoymiles that harmonizes with the set Hoymilesand a DTU-wLite, which collects information and data from the microinverter and transmits it to the Hoymiles monitoring system S-Miles Cloud via wLAN technology. Suitable connection and connection cables are included so that everything can be combined. Thanks to the plug and play principle and the compact design, you will find it very easy to set up without any annoying cable chaos. Plug and play - plug in and save money Control your own consumption Make your lifestyle more environmentally friendly Quickly amortizing investment how does the All-In-One system work? during the Day the pv hub directs the energy generated by the pv modules to the micro inverter, which converts it into alternating current to supply your household appliances with electricity. excess energy is intelligently stored in the battery so that it can also be used at night At night use at night. This efficient use enables savings of up to €642.4 per year. The complete balcony power station set contains: 1x Zendure All-In-One 2.4kwh LiFePO4 battery storage system + pv hub for balcony power plants 3x Luxen Solar 405w Mono Bifacial Glass-Glass Solar Panel Luxneri Series S5 1x Hoymiles hm-1200 Microinverter Module inverter 1x Hoymiles DTU-wLite data transmission and control unit 1x 5m connection cable micro inverter with Betteri bc01 socket to Schuko socket (angled plug) 1x Offgridtec 2-way junction sockets Y-connector incl. cable extension (pair) 1x Hoymiles disconnect tool for ac box hms microinverter disconnect tool 2x Connection cable mc4 to mc4 6mm² 5m red/black All-In-One 2.4kwh LiFePO4 battery storage system The All-In-One energy solution (mpn: ZDaio2400-gy) from Zendure is a 2.4 kWh storage system for balcony power plants that you can install yourself in just a few minutes. The device offers you a cycle-proof LiFePO4 battery including smart pv hub in a slim housing. Thanks to the advanced self-heating technology, the aio 2400 can continue to work even in winter environments at sub-zero temperatures. This means that the battery temperature always remains above 0°C for normal operation. Thanks to its IP65 protection class, the set can be placed on your balcony, in the garden or in the living room, regardless of whether it is raining or snowing. In addition to protection against environmental influences, the system impresses with a low noise level of 0dB. You have the choice of hanging the cylinder on the wall or standing it on the floor. Everything you need for both is included in the scope of delivery. Plug and play - plug in and get started Smart control via app Dual 1200w mppt Battery chemistry: LiFePO4 Self-heating function: rechargeable at up to -20°C Intelligent energy management Compact design Save space during installation No cable chaos Manufacturer's guarantee: 10 years Technical data Capacity: 2.4 kwh Battery chemistry: LiFePO4 efficiency mppt: 99% efficiency of the output: 98% Charging temperature: 0°C - +55°C Discharging temperature: -20°C - +60°C 4000 cycles (useful capacity 80%) 8000 cycles (useful capacity 70%) Protection class: IP65 Weight: 31.3 kg Weight with bracket: 37 kg Dimensions: 657 x 427 x 150 mm Luxen Solar 405w solar module The monocrystalline and bifacial solar module 405w S5 from Luxen Solar (mpn: LNVB-405MD) impresses with a combination of different technologies, such as doping with the metal gallium, which prevents the phenomenon of light-induced degradation. Half-cell technology was also used in production to increase performance. And the manufacturer Luxen is confident in its product: it guarantees a 30-year service life. At a glance - the Luxen S5 Gallium doping reduced hot-spot temperature Half-cut cell technology high cell efficiency of over 20% 30-year performance guarantee and 12-year product guarantee TÜV Rheinland certified: pv 50585684 Technical data maximum power: 405w Module voltage (Vmp): 37.33V max. current (Imp): 10,85A Open circuit voltage (Voc): 44.42V Short-circuit current (Isc): 11.82A Module efficiency: 20.74% Dimensions: 1722 x 1134 x 30 mm Operating temperature range: -40°C to +85°C max. operating voltage: 1500v DC Weight: 23.5 kg hm-1200 The hm-1200 fromHoymiles is the perfect micro inverter for your balcony power plant. The compact lightweight (only 3.75kg including the 2.06m ac cable) is suitable for solar power production with up to four solar panels up to an output of 380w each. Just like all other micro inverters from Hoymiles, it is suitable for long operating hours and wide pv module applications, as its starting voltage is very low (only 22v) and the DC input range of the operating voltage (16-60V) is extremely wide. Minimizing the effects of e.g. shading, dust or aging due to mppt High quality energy harvesting with high mppt accuracy Optimum system reliability Peak efficiency of 96.7% High level of safety thanks to integrated protective functions 6000V surge protection 12-year product guarantee Complies with vde-ar-n 4105: 2018 & EN50549-1:2019 Technical data Recommended module power: 240 - 405w (per module) Peak power mppt of the voltage range: 29~48V Starting voltage: 22V Operating voltage range: 16~60V Maximum input voltage: 60V Maximum input current: 4*11.5A Maximum input short-circuit current: 4*15A Rated output power: 1200VA Rated output current: 5.22a at 230v Nominal output voltage/range: 230v 180-275V CEC-weighted efficiency: 96.50% Ambient temperature range: -40~+65°C Enclosure rating: IP67 Dimensions (WxHxD): 280 x 176 x 33 mm Weight: 3.75kg (including 2.06m ac-cable) DTU-wLite The Hoymiles Gateway DTU-wLite is a data transmission unit that uses 2.4G wireless communication to collect information and data from microinverters and transmits it to the Hoymiles monitoring system S-Miles Cloud via wifi technology. With the help of your DTU-wLite, you can easily read the data and alarms at module level and realize and store remote operation and maintenance of the microinverter system anytime and anywhere via the Hoymiles S-Miles Cloud. The monitoring capacity is limited to 4 modules. monitoring at module level, with up to 4 solar modules Simple installation thanks to plug and play Remote maintenance of the system via the S-Miles Cloud Direct connection (USB port) Data and alarms from microinverters on S-Miles Toolkit in real time LED display Technical data Type: Proprietary 2.4 GHz protocol (Nordic) Maximum distance (open area and depending on installation environment): up to 150m Limitation of monitoring data from solar panels: 4 Signal: wLAN:802.11b/g/n Sampling: Every 15 minutes Local app: S-Miles Toolkit Power consumption type 1.0 w / max. 5.0 w Input voltage: 5V Ambient temperature range: -20 to +55°C Dimensions (WxHxD): 143 x 33 x 12.5 mm Weight: 0.1 kg Certificate: CE

Die Backup-Systeme von Offgridtec sind ideal zur Notstromversorgung oder zur Erweiterung eines bestehenden Solarsystems geeignet. Die Systeme enthalten neben Lithium-Ionen Akkus von Pylontech, einen passenden MultiPlus-II Wechselrichter und einen Cerbo GX zur Systemüberwachung von Victron Energy. Damit kannst du deine Energieversorgung auch dann sicherstellen, wenn es zu einem Stromausfall kommt. Dank der UPS-Funktion bleibt der MultiPlus auch bei einem Netzfehler eingeschaltet und übernimmt die Versorgung der angeschlossenen Verbraucher. Die Umschaltung geschieht so schnell (in weniger als 20 Millisekunden), dass ein unterbrechungsfreier Betrieb von Computern und anderen elektronischen Geräten gewährleistet werden kann. Einsatzgebiete des Offgridtec Backup-Kits: Notstromversorgung Netzunabhängige Solarsysteme (Inselanlagen) Nachrüstung bestehender PV-Anlagen Netzgekoppelte Stromversorgung USV-Anlagen Was enthält das Offgridtec Backup-System? Pylontech US3000C 3,5kWh LiFePO4 Akku (je nach Auswahl 2x, 4x oder 6x) 3x Victron MultiPlus-II 48/5000/70-50 230V Gerätekombination 2x Victron Lynx Distributor 1x Victron Cerbo GX Bedienpanel 1x Victron GX Touch 50 Anzeigepanel für Cerbo GX 1x Victron MK3-USB Ve.Bus zu USB Interface 1x 1,8m VE.Can zu Can-Bus BMS Typ A Kabel 2x 0,9m Victron RJ45 UTP Kabel 1x 3m Victron RJ45 UTP Kabel 3x 1m Offgridtec Batteriekabel 35mm² M8-Ösen 3x 200A 70V MEGA Sicherung Pylontech Batterieanschlusskabelset (je nach Auswahl 1x oder 2x) Erweiterte Nutzung deines Backup-Systems Um ein ESS (Energy Storage System) mit dem Backup-System errichten zu können, wird jeweils ein Energiezähler mit Anschlusskabel benötigt: Victron VM-3P75CT Energy Meter 3-phasiger Stromzähler 75A/phase 5m Victron RJ45 UTP Kabel Mit diesem Stromzähler kannst du eine netzparallele Installation vornehmen und danach deinen Energieverbrauch überwachen, bzw. deine Energiekosten kontrollieren. Dank der Phasenkompensation könntest du sogar den 3-phasigen Zähler auch für 1-phasige Systeme nutzen. Damit sind nahtlose Integrationen von dezentralen Energiequellen und Verbrauchern in das bestehende Stromnetz kein Problem. Damit ein ESS in der Vorkonfiguration berücksichtigt werden kann, muss der Zähler zwingend im Vorfeld bzw. zum System erworben werden! Die Speicherlösung – Pylontech US3000C Akkus Der US3000C Speicher ist ein Lithiumakku der neuesten Generation. Er wurde speziell für die hohen Ansprüche, die an Backup-Speicher gestellt werden, zu erfüllen. Dank hochmoderner Technologie sind höchste Sicherheit und eine lange Lebensdauer auch bei regelmäßiger tiefer Entladung garantiert. Extrem zyklenfest – über 6000 Zyklen bei 95% DoD Absolut eigensichere Lithiumtechnologie Hohe Lade- und Entladeleistung möglich Integriertes BMS Sehr hohe Speicherdichte – geringes Gewicht und kompakte Bauweise Absolut wartungsfrei und langlebig Vorladefunktion zum Schutz des ESS-Systems vor Überspannungsfunktion Der Elektronik-Kern – die Victron Multiplus-II Gerätekombination Der Multiplus-II 48/5000/70-50 ist eine High-End Gerätekombination von Victron Energy (MPN PMP482505010) die klassische Multiplus-Komponenten mit einem externen Stromsensor und integrierter Anti-Islanding Funktion verbindet. Dadurch werden die Funktionen PowerControl und PowerAssist auf 100 A erweitert und der potenzielle Einsatzbereich auf ESS-Anwendungen ausgedehnt. Das Wechselrichter Modul leistet bei nicht linearer Belastung satte 5000 W, bzw. 4000 W bei linearer Dauerbelastung. Auch das 48 V Batterieladegerät ist mit 70 A Ladeleistung sehr gut proportioniert und wird durch einen 50 A Transferschalter ergänzt, mit dem sich blitzschnell zwischen den AC-Anschlüssen hin- und herschalten lässt. wichtige Leistungsmerkmale des Multiplus-II 48/5000/70-50 PowerControl und PowerAssist –Steigerung von Netz-oder Generator-Leistung eingebaute Anti-Islanding-Funktion und Anschlussmöglichkeit für externen Stromsensor (optional) kann als Backupgerät in netzgekoppelten Anlagen eingesetzt für die Stromversorgung bei Netzausfällen einsetzbar in verschiedenen ESS (Energy Storage System) Anwendungen bestens geeignet für die professionelle Seefahrt, Yachten, Fahrzeuge und landgebundene, netzferne Anwendungen VE.Bus Schnittstelle für Parallel-und Drei-Phasen-Betrieb, Fernüberwachung und Systemintegration praktisch unbegrenzte Leistung durch Parallel-und Drei-Phasen-Betrieb kann vor Ort oder aus der Ferne mittels VEConfigure Software konfiguriert werden Immer genug Power dank PowerControl und PowerAssist Am Multiplus-II 48/5000/70-50 kann ein maximaler Netz- oder Generatorstrom eingestellt werden. Das MultiPlus-II nimmt dann Rücksicht auf weitere angeschlossene Wechselstromverbraucher und nutzt zum Laden der Batterie nur den Strom, der noch „übrig“ ist. So wird verhindert, dass der Generator- oder der Netzanschluss überlastet wird (PowerControl-Funktion). Mit der Funktion PowerAssist erhält das PowerControl-Prinzip eine neue Dimension. Lastspitzen treten häufig nur für einen begrenzten Zeitraum auf. In einem solchen Fall kompensiert das MultiPlus-II zu schwache Generator-, Landstrom- bzw. Netzleistung sofort durch Energie aus der Batterie. Wird die Last reduziert, d. h. werden Verbraucher ausgeschaltet, kann die dann wieder ausreichend vorhandene Energie zum Laden der Batterien genutzt werden. Maximale Flexibilität dank zweier Wechselstromausgänge Der Hauptausgang stellt einen unterbrechungsfreien Betrieb sicher. Im Falle eines Netzausfalls oder bei einer Unterbrechung des Land-/Generatorstroms übernimmt das MultiPlus-II die Versorgung der angeschlossenen Verbraucher. Die Umschaltung geschieht so schnell (in weniger als 20 Millisekunden), dass ein unterbrechungsfreier Betrieb von Computern und anderen elektronischen Geräten gewährleistet ist. Der zweite Ausgang liefert nur dann Strom, wenn am Eingang des MultiPlus-II Wechselstrom verfügbar ist. Verbraucher, die die Batterie nicht entladen dürfen, wie z. B. ein Wassererhitzer, können an diesen Ausgang angeschlossen werden. Konfiguration und Überwachung aus der Ferne Installieren Sie ein Color Control GX oder andere GX-Produkte, um sich mit dem Internet zu verbinden. Die Betriebs-Daten lassen sich auf unserer VRM (Victron Remote Management) Website kostenlos speichern und einsehen. Sind Systeme an das Internet angeschlossen, kann auf sie aus der Ferne zugegriffen und Einstellungen können geändert werden. Die Auslieferung des MultiPlus-II erfolgt standardmäßig unkonfiguriert. Sie finden hier im Downloadbereich die Konfigurations-Anleitung für das System. Sollten Sie eine Vorkonfiguration durch uns wünschen, können wir dies gern gegen Aufpreis für Sie übernehmen. Hierzu legen Sie den oben verlinkten Artikel "Offgridtec Vorkonfiguration" beim Bestellvorgang in den Warenkorb. Der Versand kann in diesem Fall 3-5 Werktage länger in Anspruch nehmen, bis die Konfiguration durchgeführt wurde. Technische Merkmale 5000 W Leistung bei nicht linearer Belastung 4000 W Dauerbelastung und 9000 W Spitzenleistung für 48 V Batteriespannung, 50 A Transfer-Schalter und 70 A Batterieladegerät Ausgangsspannung: 230 VAC, Frequenz: 50 Hz max. Wirkungsgrad liegt bei 95%, Schutzklasse IP22 Systemüberwachung mit dem Victron Cerbo GX und GX Toch Display Mit der Cerbo GX Kommunikationszentrale können Sie Ihr System ganz einfach kontrollieren und überwachen. Die flexiblen Verbindungsmöglichkeiten maximieren Ihre Systemleistung. Die Kontrolle Ihrer Anlage ist dank des Cerbo GX ortsunabhängig möglich. Mit dem GX Touch 50 Display haben Sie alle Parameter Ihres Systems stets im Blick und können Änderungen einfach und schnell vornehmen. Sicherheitshinweis: Lassen Sie dieses Komplettsystem nur von einer Elektrofachkraft installieren und in Betrieb nehmen.

Die Backup-Systeme von Offgridtec sind ideal zur Notstromversorgung oder zur Erweiterung eines bestehenden Solarsystems geeignet. Die Systeme enthalten neben Lithium-Ionen Akkus von Pylontech, einen passenden MultiPlus-II Wechselrichter und einen Cerbo GX zur Systemüberwachung. Damit kannst du deine Energieversorgung auch dann sicherstellen, wenn es zu einem Stromausfall kommt. Dank der UPS-Funktion bleibt der MultiPlus auch bei einem Netzfehler eingeschaltet und übernimmt die Versorgung der angeschlossenen Verbraucher. Die Umschaltung geschieht so schnell (in weniger als 20 Millisekunden), dass ein unterbrechungsfreier Betrieb von Computern und anderen elektronischen Geräten gewährleistet werden kann. Einsatzgebiete des Offgridtec Backup-Kits: Notstromversorgung Netzunabhängige Solarsysteme (Inselanlagen) Nachrüstung bestehender PV-Anlagen Netzgekoppelte Stromversorgung USV-Anlagen Was enthält das Offgridtec Backup-System? Pylontech US5000C 3,5kWh LiFePO4 Akku (je nach Auswahl 4x, 6x oder 8x) 3x MultiPlus-II 48/8000/110-100/100 230V Gerätekombination 2x Victron Lynx Distributor 1x Victron Cerbo GX Bedienpanel 1x Victron GX Touch 50 Anzeigepanel für Cerbo GX 1x Victron MK3-USB Ve.Bus zu USB Interface 1x 1,8m VE.Can zu Can-Bus BMS Typ A Kabel 2x 0,9m Victron RJ45 UTP Kabel 1x 3m Victron RJ45 UTP Kabel 6x 1m Offgridtec Batteriekabel 35mm² M8-Ösen 6x 200A 70V MEGA Sicherung 2x Pylontech Batterieanschlusskabelset  Erweiterte Nutzung deines Backup-Systems Um ein ESS (Energy Storage System) mit dem Backup-System errichten zu können, wird jeweils ein Energiezähler mit Anschlusskabel benötigt: Victron VM-3P75CT Energy Meter 3-phasiger Stromzähler 75A/phase 5m Victron RJ45 UTP Kabel Mit diesem Stromzähler kannst du eine netzparallele Installation vornehmen und danach deinen Energieverbrauch überwachen, bzw. deine Energiekosten kontrollieren. Dank der Phasenkompensation könntest du sogar den 3-phasigen Zähler auch für 1-phasige Systeme nutzen. Damit sind nahtlose Integrationen von dezentralen Energiequellen und Verbrauchern in das bestehende Stromnetz kein Problem. Damit ein ESS in der Vorkonfiguration berücksichtigt werden kann, muss der Zähler zwingend im Vorfeld bzw. zum System erworben werden! Die Speicherlösung – Pylontech US5000C Akkus Der US3000C Speicher ist ein Lithiumakku der neuesten Generation. Er wurde speziell für die hohen Ansprüche, die an Backup-Speicher gestellt werden, zu erfüllen. Dank hochmoderner Technologie sind höchste Sicherheit und eine lange Lebensdauer auch bei regelmäßiger tiefer Entladung garantiert. Extrem zyklenfest – über 6000 Zyklen bei 95% DoD Absolut eigensichere Lithiumtechnologie Hohe Lade- und Entladeleistung möglich Integriertes BMS Sehr hohe Speicherdichte – geringes Gewicht und kompakte Bauweise Absolut wartungsfrei und langlebig Vorladefunktion zum Schutz des ESS-Systems vor Überspannungsfunktion Der Elektronik-Kern – die Victron Multiplus-II Gerätekombination Der Multiplus-II ist eine High-End Gerätekombination von Victron Energy, bestehend aus 48V Batterieladegerät, Wechselrichter und Transfer-Schalter. Diese Kombination verbindet die klassischen Multiplus-Komponenten mit einem externen Stromsensor und integrierter Anti-Island-Funktion. Dadurch werden die Funktionen PowerControl und PowerAssist auf 50A erweitert und der potenzielle Einsatzbereich auf Energy-Storage-System Anwendungen ausgedehnt. Der Multiplus kann daher ideal als Backupgerät in netzgekoppelten und -unabhängigen Anlagen für die Stromversorgung eingesetzt werden. 8000 W Leistung bei nicht linearer Belastung 6400 W Dauerbelastung und 15000 W Spitzenleistung für 48V Batteriespannung 100A Transferschalter 110A Batterieladegerät Ausgangsspannung: 230 VAC, Frequenz: 50 Hz max. Wirkungsgrad: 95% Schutzklasse: IP22 Konfiguration Die Auslieferung des MultiPlus-II erfolgt standardmäßig unkonfiguriert. Sie finden hier im Downloadbereich die Konfigurations-Anleitung für das System. Sollten Sie eine Vorkonfiguration durch uns wünschen, können wir dies gern gegen Aufpreis für Sie übernehmen. Hierzu legen Sie den oben verlinkten Artikel "Offgridtec Vorkonfiguration" beim Bestellvorgang in den Warenkorb. Der Versand kann in diesem Fall 3-5 Werktage länger in Anspruch nehmen, bis die Konfiguration durchgeführt wurde. Systemüberwachung mit dem Victron Cerbo GX und GX Toch Display Mit der Cerbo GX Kommunikationszentrale können Sie Ihr System ganz einfach kontrollieren und überwachen. Die flexiblen Verbindungsmöglichkeiten maximieren Ihre Systemleistung. Die Kontrolle Ihrer Anlage ist dank des Cerbo GX ortsunabhängig möglich. Mit dem GX Touch 50 Display haben Sie alle Parameter Ihres Systems stets im Blick und können Änderungen einfach und schnell vornehmen. Sicherheitshinweis: Lassen Sie dieses Komplettsystem nur von einer Elektrofachkraft installieren und in Betrieb nehmen.

Die Solar-Direct Komplettsysteme von Offgridtec bieten dir eine ausgezeichnete Möglichkeit einen Teil deines benötigten Haushaltsstroms selbst zu erzeugen und dadurch die Gesamtausgaben für Strom erheblich zu reduzieren. Dieses System enthält neben den vier 405W starken Glas-Glas Modulen den perfekt dazu passenden und kompakten Mikrowechselrichter HMS-1600-4T. Um alles miteinander verbinden zu können steht ein HMS-Anschlusskabel zur Verfügung, welches mit dem Plug and Play Prinzip sehr leicht zu installieren ist. Optional steht ein DTU-Lite-S zur Auswahl, der die Informationen und Daten des Wechselrichters mit Hilfe einer Sub-1G-Funklösung erfasst und sie über WLAN-Technologie an das Hoymiles Überwachungssystem S-Miles Cloud übermittelt. Half-Cut Zelltechnologie reduzierte Hot-Spot Temperatur Hochwertige Energiegewinnung mit hoher MPPT-Genauigkeit Optimale Systemzuverlässigkeit Das Solaranlagen-Komplettsystem enthält: 4x Luxen Solar 405W Mono Bifazial Glas-Glas Solarmodul Luxneri Series S5 1x Hoymiles HMS-1600-4T Microinverter Modulwechselrichter 1x Hoymiles HMS-Anschlusskabel Field Connector Plug&Play (Länge wählbar 5m – 10m – 15m) 1x Hoymiles Trennhilfe für AC Box HMS Microinverter Disconnect Tool Optional wählbar: Hoymiles DTU-Lite-S WLAN Datenübertragungseinheit für HMT / HMS Luxen Solar 405W Glas-Glas Solarmodul Das monokristalline und bifaziale Solarmodul 405W S5 von Luxen Solar (MPN: LNVB-405MD) überzeugt durch eine Kombination verschiedener Technologien, wie zum Beispiel der Dotierung mit dem Metall Gallium, die das Phänomen der lichtinduzierten Degradation vorbeugt. Zur Leistungssteigerung wurde bei der Produktion außerdem die Halbzellen-Technologie angewandt. Und der Hersteller Luxen vertraut auf sein Produkt: Er garantiert eine 30-jährige Lebensdauer. Galliumdotierung reduzierte Hot-Spot Temperatur Half-Cut Zelltechnologie hoher Zellwirkungsgrad von über 20% 30 Jahre Leistungsgarantie und 12 Jahre Produktgarantie TÜV Rheinland Zertifiziert: PV 50585684 Technische Daten maximale Leistung: 405W Modulspannung (Vmp): 31,62V max. Strom (Imp): 12,81A Leerlaufspannung (Voc): 37,74V Kurzschlussstrom (Isc): 13,70A Modulwirkungsgrad: 20,74% Abmessungen: 1722 x 1134 x 30 mm Betriebstemperaturbereich: -40°C bis +85°C max. Betriebsspannung: 1500V DC Anzahl der Zellen: 108 (6x18) Gewicht: 23,5 kg HMS-1600-4T Der HMS-1600 (MPN: HMS-1600-4T) von Hoymiles ist der perfekte Mikrowechselrichter für Ihr Balkonkraftwerk. Das kompakte Leichtgewicht (nur 4,7kg) eignet sich für die Solarstromproduktion mit bis zu vier Solarpanelen bis zu einer Leistung von je 320W bis 540W+. Genauso wie bei allen anderen Mikrowechselrichtern von Hoymiles ist er für lange Betriebsstunden und breiter PV-Modulanwendung geeignet, da seine Inbetriebnahme sehr niedrig (nur 22V) und der DC-Eingangsbereich der Betriebsspannung (16-60V) extrem breit ist. Gegenüber dem Vorgängermodel aus der HM-Serie bietet der HMS-1600-4T mehr Sicherheit für Aufdach-Solarkraftwerke durch Schnellabschaltung und isolierten Transformator. Die neue Sub-1G-Funklösung ermöglicht eine stabilere Kommunikation mit dem Hoymiles-Gateway DTU. Minimierung der Auswirkungen von z.B. Verschattung, Staub oder Alterung durch MPPT Hochwertige Energiegewinnung mit hoher MPPT-Genauigkeit Optimale Systemzuverlässigkeit Spitzenwirkungsgrad von 96,7% 12 Jahre Produktgarantie Hohe Sicherheit durch integrierte Schutzfunktionen Einfache Installation Lange Lebensdauer Entspricht EN50549-1:2019, VDE-AR-N 4105: 2018, VFR2019, IEC/EN 62109-1/-2, IEC/EN 61000-6-1/-2/-3/-4, IEC/EN 61000-3-2/-3 Technische Daten Empfohlene Modulleistung: bis zu 320W - 540+W (je Modul) MPPT Spannungsbereich: 16-60V Einschaltspannung: 22V Maximale Eingangsspannung: 65V Maximaler Eingangsstrom: 4*12,5A Maximaler Eingangskurzschlussstrom: 4*20A Nennausgangsleistung: 1600VA Nennausgangsstrom: 6,96A Nennausgangsspannung/-bereich: 230V / 180-275V CEC Spitzenwirkungsgrad: 96,70% Umgebungstemperaturbereich: -40°C - +65°C Abmessungen (BxHxT): 331 x 218 x 36,6 mm Gewicht: 4,7kg Gehäuseeinstufung: IP67 DTU-Lite-S Das Hoymiles-Gateway DTU-Lite-S ist eine Datenübertragungseinheit, die Informationen und Daten von Mikrowechselrichtern mit Hilfe einer Sub-1G-Funklösung erfasst und sie über WLAN-Technologie an das Hoymiles-Überwachungssystem S-Miles Cloud übermittelt. Einfache Installation dank Plug and Play Überwachung auf Modulebene, mit bis zu 99 Solarmodulen Daten und Alarme von Mikrowechselrichtern auf S-Miles Toolkit in Echtzeit Fernwartung des Systems über die S-Miles Cloud Direktanschluss (USB-Port) Funktionsweise Die Datenübertragungseinheit DTU-Lite-S hat eine Überwachungskapazität für bis zu 99 Solarmodule. Dadurch ist das System optimal für die unterschiedlichsten PV-Anlagen geeignet. Die Daten und Alarme können die Benutzer auf Modulebene einfach und schnell ablesen. Der Fernbetrieb sowie die Fernwartung des PV-Systems lässt sich jederzeit und von jedem Ort bequem über die Hoymiles S-Miles Cloud vornehmen. S-Miles Accounterstellung Die Erstellung des S-Miles Accounts kann direkt vom Endnutzer vorgenommen werden. Im Downloadbereich dieses Artikels ist hierzu die Anleitung von Hoymiles zu finden. Technische Daten Typ: Sub-1G Maximale Entfernung (offenes Gelände und je nach Installationsumgebung): bis zu 400m Begrenzung der Überwachungsdaten von Solarmodulen: 99 Signal: WLAN:802.11b/g/n Abtastung: Alle 15 Minuten LED-Anzeige Lokale APP: S-Miles Toolkit Leistungsaufnahme Typ 1,0 W / max. 5,0 W Eingangsspannung: 5V Umgebungstemperaturbereich: -20 bis +55°C Abmessungen (BxHxT): 143 x 33 x 12,5 mm Gewicht: 0,1kg Zertifikat: CE, FCC, IC, RCM, Anatel Modell des Mikrowechselrichters: HMS und HMT-Serie HMS-Anschlusskabel Field Connector Plug&Play Das Hoymiles HMS Plug&Play-Verbindungskabel ist speziell für den Einsatz in PV-Anlagen mit nur einem HMS-Wechselrichter konzipiert. Es besteht aus einem Field-Connector, einem AC-Kabel und einem AC-Stecker. Der Field-Connector wird an den Inverter und der Stecker an die Haushaltssteckdose angeschlossen. Diese einfache Plug-and-Play-Konstruktion ermöglicht es dem Benutzer, das einzelne Wechselrichtersystem einfach und schnell an das Netz anzuschließen. Der Anschluss an das Stromnetz darf nur von einem Elektriker vorgenommen werden. Hoymiles HMS Kabelsystem Das HMS-Kabelsystem ist eine innovative Lösung zur Verkabelung von Hoymiles HMS-Wechselrichtern in PV-Anlagen. Es bietet ein benutzerfreundliches Plug-and-Play-Design, das eine einfachere, schnellere und zuverlässigere Installation ermöglicht. Das flexible HMS-Kabelsystem erlaubt es dem Benutzer, Kabel unterschiedlicher Größe oder Länge zu kombinieren, um die gewünschte Verkabelungskonfiguration kostengünstig umzusetzen. Technische Daten Komponenten: HMS Field Connector + Kabel + AC-Stecker Kabeltyp: PV07AC-F Kabellänge: 3m Durchmesser: 1,5mm² Nennspannung: 250V Nennstrom: 12A Temperaturbereich: -40 bis 85°C
