H07RN-F 1x16mm high-end rubber cable Lapp 1600195
Product number:
8-04-006830
8-04-006830
Product number:
8-04-006830
The H07RN-F cable from Lapp (MPN 1600195) is a high-quality solution for demanding applications. These heavy-duty rubber hose cables are ideal for use in dry or damp rooms as well as outdoors.
The single-core H07RN-F rubber hose cables can be used for short-circuit-proof and earth-fault-proof installations in accordance with VDE 0100-520. Areas of application in accordance with EN 50565-2 include dry and damp rooms as well as outdoor use, taking into account all normative cable properties. They are ideal for devices in commercial and agricultural workshops, power tools, portable motors, and machine tools.
Structure
- Construction: in accordance with EN 50525-2-2-21
- Certification: The cable is marked with the ⊲HAR⊳ -HARmonization mark or HARmonization thread.
- Conductor: fine-stranded bare copper strands in accordance with IEC 60228 or EN 60228, class 5
- Conductor insulation: Rubber compound type EI4 in accordance with EN 50363-1
- Conductor marking:
up to and including 5 cores: colored according to VDE 0293-308, with or without GN-GE protective conductor
6 or more cores: black cores with white numbers with GN-GE protective conductor, in accordance with EN 50334 - Outer sheath: Rubber compound type EM2 according to EN 50363-2-1
Electrical properties at 20 °C
- Nominal voltage: U₀/U: 450/750 V
- Test voltage: A / A: 2500 V AC
Mechanical and thermal properties
- Minimum bending radius: 4 to 8 x outer diameter according to EN 50565-1 Tab.3
- Temperature range: from -25°C to +60°C max. Conductor temperature
- Flammability: according to IEC 60332-1-2 or EN 60332-1-2
- oil resistance: according to EN 50363-2-1
- Tests: in accordance with IEC 60811, EN 50395, EN 50396
- General requirements: The cables comply with EU Directive 2014/35/EU (Low Voltage Directive)
- Environmental information: The cables meet the material requirements of EU Directive 2011/65/EU (RoHS).
