Kemo amplifier 40 W, universal M034
Product number:
2-12-00M034
2-12-00M034
Robust amplifier module for universal use. The module is moisture-proof and vibration-proof. The encapsulation compound and the module housing are made of a special, highly thermally conductive plastic. Therefore, no additional heat sinks are required. The module is electronically protected against overheating and overload.
Technical data:
Music power: max. 40 W at 4 ohm speaker load at 16 V operating voltage
Operating voltage: 6 - 16 V
Connectable speakers: 4 - 8 ohms
Sensitivity: < 500 mV
Frequency range: approx. 20 - 25,000 Hz
Dimensions: approx. 70 x 45 x 29 mm (with cooling bracket)
Technical data:
Music power: max. 40 W at 4 ohm speaker load at 16 V operating voltage
Operating voltage: 6 - 16 V
Connectable speakers: 4 - 8 ohms
Sensitivity: < 500 mV
Frequency range: approx. 20 - 25,000 Hz
Dimensions: approx. 70 x 45 x 29 mm (with cooling bracket)
Manufacturer:
Kemo Electonic
Manufactuerer Information
Kemo Electronic
Kemo-Electronic GmbH
Leher Landstr. 20
27607 Geestland
Germany
Mail: info@kemo-electronic.de
Tel.: +49 4743 93380
