Offgridtec USB double socket 5-20V - 60W
Product number:
8-01-014900
8-01-014900
Preorder 08.12.2025
Product is expected to be back in stock on 8 December 2025
€15.27*
Product number:
8-01-014900
The USB double socket from Offgridtec allows you to use two USB-C connectors via a dual port. The USB cover provides additional protection when the product is not in use. It can also be removed from the socket. The dual socket is suitable for use with mounting enclosures.
Product information
- Protection class: IP65
- Terminals: Copper/nickel coating 1/4" (6.3 mm)
- Material: Plastic
- Color: Black
Protective functions
- overvoltage protection
- overcurrent protection
- overheating protection
- Short-circuit protection
- Reverse polarity protection
Technical
- Nominal voltage: 12V/24V DC
- Operating voltage: 12V/32V DC (max.)
- Peak voltage: 36V DC (max. 3-4 seconds)
- Operating frequency: 100-150kHz
- Current consumption (quiescent current): 20mA
- Operating temperature range: -20°C to +60°C
Input: 12V
- Type C1 output: 5V-12V (max. 36W)
- Type C2 output: 5V-12V (max. 36W)
- Type C1 + Type C2: 36W + 36W
Input: 24V
- Type C1 output: 5V-20V (max. 60W)
- Type C2 output: 5V-20V (max. 60W)
- Type C1 + Type C2 60W + 60W
Dimensions
- Total length: 69.9 mm
- Diameter: 36.5 mm
Scope of delivery:
1x Offgridtec USB double socket (2x USB-C)
8-01-014900_Offgridtec_USB-Doppelsteckdose.pdf
Download
Manufacturer:
Offgridtec
Product Type:
Plug
Protection type:
IP65
Manufactuerer Information
Offgridtec AG
Offgridtec AG
Im Gewerbepark 11
84307 Eggenfelden
Germany
Mail: info@offgridtec.com
Tel.: +49 8721 9199400
8-01-014900
Wieviel Ampere zieht die Doppelsteckdose maximal?
Diese Doppelsteckdose zieht maximal 6A unter voller Auslastung.
