Growatt TPM-CT-E 100A 3-phase smart meter including current transformer
Product is expected to be back in stock on 19 June 2026
€193.21*
€162.36**
Similar Products
Product is expected to be back in stock on 17 June 2026
Product is expected to be back in stock on 17 June 2026
Product is expected to be back in stock on 19 June 2026
Product is expected to be back in stock on 19 June 2026
Soon available again
Soon available again
The TPM-CT-E electricity meter from Growatt is a 3-phase multifunctional measuring device for precise monitoring. The meter works with three external current transformers and is versatile, suitable for use in both high- and low-voltage networks. This single solution can be used to limit grid feed-in and monitor self-consumption. You can easily read the smart meter data in real time on the LCD display. With RS485 communication and a direct connection to the inverter, installing the meter is inexpensive and easy.
The TPM-CT-E smart meter at a glance
- Meter with 3 current transformers
- For three-phase systems
- Control of export power and own consumption
- High measurement accuracy (class 1)
- Quick installation – plug & play
- For 1P2W/3P3W/3P4W networks
- LCD display
- Mounting type: 35 mm DIN rail
- Meter with CT for simplified cabling
Technical
- Nominal voltage: 3x230V / 400V AC
- Max. current: 100 A
- Current type: 3P4W
- Input voltage: 173 - 480V AC (L-L)
- Communication: RS485, Modbus-RTU
- Operating temperature range: -25°C - +55°C
- Storage temperature range: -40°C - +70°C
- Frequency: 50/60Hz
- Humidity: 0 to 90%, non-condensing
- Weight: 280 g
- Dimensions: 94.5 x 72 x 65 mm
- Protection class: IP51
- RS485 cable length: 15 m
- CT*3 cable length: 5 m
Scope of delivery
1x Growatt TPM-CT-E Smart Meter electricity meter
3x 5m CT cables
1x 15m RS485 cable
