Hoymiles HiFlow 2000 Pro HMS-2000-4WB Microinverter 2000 VA Wi-Fi & Bluetooth

The Hoymiles HiFlow 2000 Pro HMS-2000-4WB microinverter (MPN: HMS-2000-4WB) is a 4-in-1 microinverter for mini and balcony solar systems with up to four PV modules. With a rated output power of 2,000 VA, four independent MPPT trackers, and built-in Wi-Fi and Bluetooth, the device enables individual energy conversion for each module and easy monitoring via the S-Miles Home app. The Flex-S3 plug-and-play system further simplifies the AC-side connection.

2,000 VA microinverter for up to four PV modules

• 2,000 VA rated output power at 230 V
• 4 independent MPPT trackers with four PV inputs
• For commonly used PV modules ranging from 400 to 670+ W
• Up to 16 A input current per MPPT
• MPPT voltage range from 16 to 60 V
• Built-in Wi-Fi and Bluetooth
• Monitoring and configuration via the S-Miles Home app
• Local and cloud-based system configuration
• Flex S3 plug-and-play system for AC connection
• Peak efficiency of 96.5%
• MPPT efficiency of 99.8%
• Passive cooling via natural convection
• IP67-rated enclosure for outdoor use
• Galvanic isolation via HF transformer

Four MPPT trackers for up to four solar modules

The HMS-2000-4WB features four independent MPPT trackers, each with one PV input. An MPPT continuously adjusts the electrical operating point of the connected solar module so that the available solar power can be fully utilized. The four separate trackers allow for independent control of each individual module and are particularly useful, for example, when modules have different orientations or varying irradiance conditions. The maximum input current per input is 16 A, and the maximum short-circuit current is 25 A. The MPPT voltage range extends from 16 to 60 V, and the maximum input voltage is 65 V. Hoymiles specifies a typical module power output of 400 to 670+ W per module.

Wi-Fi, Bluetooth, and the S-Miles Home App

Wi-Fi and Bluetooth are built directly into the HMS-2000-4WB. The microinverter can connect to the cloud via 2.4-GHz Wi-Fi, while Bluetooth can be used for a local connection to the S-Miles Home app. This enables both local and cloud-based system configurations as well as monitoring of operating data.

Flex-S3 Plug-and-Play for the AC Connection

For the AC connection, the HMS-2000-4WB uses the Hoymiles Flex-S3 plug-and-play system. The included cable connects the microinverter to the power grid and is equipped with a Schuko plug. The cable is 5 m long with a conductor cross-section of 1 mm².

Robust Housing and Passive Cooling

The HMS-2000-4WB measures 331 × 218 × 40.6 mm and weighs 5.6 kg. Heat dissipation occurs via natural convection without a fan. The permissible ambient temperature range is from -40 to +65 °C. With an IP67 rating, the housing is designed for outdoor use. The topology employs a galvanically isolated RF transformer.

Technical Specifications

• Typical module power: 400 to 670+ W
• Maximum input voltage: 65 V
• MPPT voltage range: 16–60 V
• Min./max. start voltage: 22/60 V
• Number of MPPT channels: 4
• Inputs per MPPT: 1
• Max. input current: 16/16/16/16 A
• Max. short-circuit current: 25/25/25/25 A

• Rated output power: 2,000 VA
• Rated output current: 8.70 A
• Rated output voltage/range: 230 V / 180–275 V
• Rated frequency/range: 50 Hz / 45–55 Hz
• Power factor: >0.99 (0.8 leading to 0.8 lagging)

• Wi-Fi: 2.4 GHz
• Bluetooth
• App: S-Miles Home
• Local and cloud-based configuration
• User Interface: LED, App

• Inverter connection: Flex-S3 field connector
• Cable cross-section: 1 mm²
• Cable length: 5 m
• Power plug: Schuko

• Dimensions (W × H × D): 331 × 218 × 40.6 mm
• Weight: 5.6 kg
• Protection rating: IP67
• Peak efficiency: 96.5%
• MPPT efficiency: 99.8%
• Power consumption at night: <50 mW
• Cooling: Natural convection
• Ambient temperature: -40 to +65 °C
• Storage temperature: -40 to +85 °C
• Topology: Galvanically isolated HF transformer

Package Contents

• 1 × Hoymiles HiFlow Pro HMS-2000-4WB microinverter
• 1 × Flex-S3 plug-and-play cable CEE7/7
• 1 × Flex-S3 cutting tool
• 1 × Installation manual
