This two-cored solar cable connects charge controller and solar modules within a system in a professional way. On the module side it is equipped with original Multi-Contact MC4-plugs - the charge controller side with ferrules. Most modules work with MC4-plugs. If not you'll find fitting adaptors in our shop. All components are prepared with professional tools and provide a high connection quality. For this cable we use either components from Helukabel or EBS-Solar - both German manufacturers. Data cable: diameter 4mm double-isolated very flexible VDE 0295 class 5 and IEC 60228 resistant against UV, ozone, weather,water, chemicals, oil fire-resistant according to VDE 0482-332-2, DIN safe from touch protection IP: unplugged - IP2X; plugged - IP67 temperature range: -40° ...60° C isolation material: PA locking-system: snap-in cable strain relief according to IEC 61984 contact system: MC Multilam contact material: tinned copper flame class: UL94-V0 protection class II system voltage up to 1000V Data ferrules: material: tinned copper length: 12mm

The USB interface cable (mpn 8-01-01120) connects a mppt Pro Duo or a psi sine wave voltage converter to a computer or notebook. Together with the free pc software (Windows only), you can conveniently read out and comprehensively configure your device comprehensive configurations can be set easier and faster via a notebook / pc compatible with mppt Pro duo charge controllers and psi sine wave voltage converters from Offgridtec Plug & Play Connector - plug in and go Scope of delivery: 8-011220 USB interface cable

This cable is used to connect all common charge controllers to a Schaudt-EBL. Features: length 1m for all common charge controllers Delivery scope:1 x EBL connection cable 1m

Designed for the use with Steca Solsum F, Steca Solarix PRS und Steca Solarix MPPT 2010. With this remote you can program your Steca solar charge controller. By using its switches all parameters can be adjusted according to your demands.After a restart and pressing the program-button the adjustments are activated. Details: low weight easy installation maintenance-free low consumption very reliable nightlight function ex works or adjustable via PA RC100 adjustment of parameters Adjustable Parameters: battery type: gel/liquid night-light function end of charge voltage (float/boost/equal) deep discharge protection (LVD) restart threshold

With this Remote + Display it is possible to control all functions of the Smart Duet charge controller indipendently from its location. Thanks to the plain design it can be integrated in every living area and shows the current data as well as past data in a numerical or graphical way. A mobile phone for example can be directly charged via the integrated USB-port. Features: remote display for the Phaesun Smart Duet MPPT charge controller displays current and past data numerical or graphical plain design USB-port for direct charging of devices with USB-power-supply

Connection cable between display and Westech MPPTcharge controller 10A - 60A Length: 10m

This Victron Energy remote display (SCC900300000) was especially designed for free programming of charge controllers out of the PWM-PRO-family.The display enables you to adjust the charge contoller's settings according to your needs - even the lighting control. It is big enough to recognize everything easily.Easier and quicker than direct programming on the charge controller via 5 buttons only. Professional functionality for the Victron PWM PRO series includedNearly every important setting, for example charging voltage, can be done freely via this optional remote panel - a feature normally found only in a higher price range.Among other settings the battery-specific charge and end-of-charge voltage as well as switch-on/off thresholds of the consumer output can be programmed. The remote panel is optional equipment and not part of the charge controllers delivery scope.All possible settings can be found in the manual. The remote display is compatible with the following Victron charge controllers:SCC010010010 Victron BlueSolar PWM-Pro 12V 24V 10A, Art-Nr 1-67-008445SCC010020110 Victron BlueSolar PWM-Pro 12V 24V 20A, Art-Nr 1-67-008445SCC010030010 Victron BlueSolar PWM-Pro 12V 24V 30A, Art-Nr 1-67-008445 Delivery scope:1x Victron SCC900300000 Remote Panel with LCD-display1x Mounting frame SCC010010010
