Offgridtec HomePremium s UsV solaranlage 8600Wp Us5000 14,4kWh 3-phase
Product number:
4-01-019485-002
4-01-019485-002
Shipped in 2-5 days
€11,688.83*
€9,822.55**
Product number:
4-01-019485-002
VAT-exempt delivery possible*
VAT-exempt order for Germany according to § 12 para. 3 UstG and Austria (§ 28 Abs. 62 UStG 1994)
§ Section 12 (3) UstG only applies if you are a private individual and the product is installed in Germany. To benefit from the 0 percent rate, please confirm at the checkout that you are eligible for the zero tax rate according to § 12 para. 3 UstG. Subsequently, the tax rate will automatically be set to zero for eligible items.
Similar Products
VAT-exempt delivery possible*
More versions available
4-01-014590-002
Offgridtec backup kit 28.8kWh Pylontech LiFePO4 battery - Victron MultiPlus II 48/10000 3-phase inverter
The backup systems from Offgridtec are ideal for emergency power supply or for expanding an existing solar system. In addition to lithium-ion batteries from Pylontech, the systems include a suitable MultiPlus-II inverter and a Cerbo GX for system monitoring from Victron Energy. This allows you to secure your energy supply even in the event of a power failure.
Thanks to the UPS function, the MultiPlus remains switched on even in the event of a mains failure and takes over the supply to the connected loads. The switchover happens so quickly (in less than 20 milliseconds) that uninterrupted operation of computers and other electronic devices can be guaranteed.
Areas of application for the Offgridtec backup kit:
Emergency power supply
Off-grid solar systems (stand-alone systems)
Retrofitting existing PV systems
Grid-connected power supply
UPS systems
What does the Offgridtec backup system contain?
Pylontech US5000 4.8kWh LiFePO4 battery (4x or 6x depending on selection)
3x Victron MultiPlus-II 48/10000/140-100 230V device combination
2x Victron Lynx Distributor
1x Victron Lynx Power In
1x Victron Cerbo GX control panel
1x Victron GX Touch 50 display panel for Cerbo GX
1x 1.8m VE.Can to Can-Bus BMS type A cable
1x 3m Victron RJ45 UTP Cable
2x 0,9m Victron RJ45 UTP Cable
6x 1m Offgridtec battery cable 50mm² M8 eyelets
4x Pylontech battery connection cable set
2x Offgridtec set of 5 MEGA fuses 200A
The Multiplus device combination is preconfigured to suit the Pylontech batteries.
Extended use of your backup system
An energy meter with connection cable is required to set up an ESS (Energy Storage System) with the backup system:
Victron VM-3P75CT Energy Meter 3-phase electricity meter 75A/phase
5m Victron RJ45 UTP Cable
With this electricity meter, you can carry out a grid-parallel installation and then monitor your energy consumption and control your energy costs. Thanks to phase compensation, you can also operate the 3-phase meter for single-phase systems. This means that seamless integration of decentralised energy sources and consumers into the existing power grid is no problem.
In order for an ESS to be taken into account in the pre-configuration, the meter must be purchased in advance or for the system!
The storage solution - Pylontech US5000 batteries
The Pylontech US5000 storage system is a lithium battery of the latest generation. It was specially developed to fulfil the high demands placed on backup storage systems. Thanks to state-of-the-art technology, maximum safety and a long service life are guaranteed even with regular deep discharges.
Extremely cycle-resistant - over 6000 cycles at 95% DoD
Absolutely intrinsically safe lithium technology
High charging and discharging capacity possible
Integrated BMS
Very high storage density - low weight and compact design
Absolutely maintenance-free and durable
Pre-charging function to protect the ESS system from overvoltage function
The electronic core - the Victron Multiplus-II device combination
The Multiplus-II is a high-end device combination from Victron Energy, consisting of a 48V battery charger, inverter and transfer switch. This combination combines the classic Multiplus components with an external current sensor and integrated anti-islanding function. This expands the PowerControl and PowerAssist functions to 50A and extends the potential range of use to energy storage system applications. The Multiplus is therefore ideal for use as a backup device in grid-connected and off-grid power supply systems.
10000W power with non-linear load - 8000W continuous load - 18000W peak power for 48V battery voltage
100A transfer switch
140A battery charger
Output voltage: 230 VAC, frequency: 50 Hz
Max. efficiency: 95
Protection class: IP22
System monitoring with the Victron Cerbo GX and GX Toch display
With the Cerbo GX communication centre, you can easily control and monitor your system. The flexible connection options maximise your system performance. Thanks to the Cerbo GX, you can control your system from anywhere. With the GX Touch 50 display, you always have an overview of all your system parameters and can make changes quickly and easily.
The backup systems from Offgridtec are ideal for emergency power supply or for expanding an existing solar system. In addition to lithium-ion batterie...
Soon available again
Soon available again
VAT-exempt delivery possible*
KfW eligible
4-01-015800
Offgridtec Backup kit 3-phase 4.8kWh with Pylontech us2000c battery Victron MultiPlus ii 48/3000
The backup systems from Offgridtec are ideal for emergency power supply or for expanding an existing solar system. In addition to lithium-ion batteries from Pylontecha suitable MultiPlus-II invertera and a Cerbo gx for system monitoring from Victron Energy. This allows you to secure your energy supply even in the event of a power failure.
Thanks to the UPS function, the MultiPlus remains switched on even in the event of a power failure and takes over the supply to the connected loads. The switchover happens so quickly (in less than 20 milliseconds) that uninterrupted operation of computers and other electronic devices can be guaranteed.
Areas of application for the Offgridtec backup kit:
Emergency power supply
Off-grid solar systems (stand-alone systems)
Retrofitting existing PV systems
Grid-connected power supply
UPS systems
What does the 3-phase Offgridtec backup system contain?
Pylontech us2000c 2.4kWh LiFePO4 battery (2x or 4x depending on selection)
3x Victron MultiPlus-II 48/3000/35-32 230v device combination
2x Victron Lynx Distributor
1x Victron Cerbo gx control panel
1x Victron gx Touch 50 display panel for Cerbo gx
1x Victron mk3-usb Ve.Bus to usb Interface
1x 1.8m VE.Can to Can-Bus bms type A cable
2x 0.9m Victron rj45 utp cable
1x 3m Victron rj45 utp cable
3x 1m Offgridtec Battery cable 35mm² M8 eyelets
3x 125A 70v mega fuse
Pylontech Battery connection cable set (depending on selection 1x or 2x)
Extended use of your backup system
To set up an ess (Energy Storage System) with the backup system, an energy meter with connection cable is required:
Victron vm-3p75ct Energy Meter 3-phase electricity meter 75A/phase
5m Victron rj45 utp cable
With this electricity meter, you can carry out a grid-parallel installation and then monitor your energy consumption and control your energy costs. Thanks to phase compensation, you can even use the 3-phase meter for 1-phase systems. This means that seamless integration of decentralized energy sources and consumers into the existing power grid is no problem.
In order for an ess to be included in the pre-configuration, the meter must be purchased in advance or for the system!
The storage solution - Pylontech us2000c batteries
The us2000c storage system is a lithium battery of the latest generation. It has been specially designed to meet the high demands placed on backup storage systems. Thanks to state-of-the-art technology, maximum safety and a long service life are guaranteed even with regular deep discharges.
Extremely cycle-resistant - over 6000 cycles at 95% DoD
Absolutely intrinsically safe lithium technology
High charging and discharging capacity possible
Integrated bms
Very high storage density - low weight and compact design
Absolutely maintenance-free and durable
Pre-charge function to protect the ess system from overvoltage
The electronic core - the Victron Multiplus-II device combination
The Multiplus-II is a high-end device combination from Victron Energy, consisting of a 48v battery charger, inverter and transfer switch. This combination combines the classic Multiplus components with an external current sensor and integrated anti-island function. This extends the PowerControl and PowerAssist functions to 50a and extends the potential range of use to energy storage system applications. The Multiplus is therefore ideal for use as a backup device in grid-connected and off-grid power supply systems.
3000W power with non-linear load - 2400w continuous load - 6000w peak power
for 48v battery voltage
32A transfer switch
35A battery charger
Output voltage: 230 vac, frequency: 50 Hz
max. efficiency: 95
Protection class: IP22
Configuration
The MultiPlus-II is delivered unconfigured as standard. You can find the configuration instructions for the system here in the download area. If you would like us to pre-configure the system for you, we can do this for you for an additional charge. To do this, add the article linked above "Offgridtec Pre-configuration" to the shopping cart during the ordering process. In this case, shipping may take 3-5 working days longer until the configuration has been completed.
System monitoring with the Victron Cerbo gx and gx Toch display
With the Cerbo gx communication center, you can easily control and monitor your system. The flexible connection options maximize your system performance. Thanks to the Cerbo gx, you can control your system from anywhere. With the gx Touch 50 display, you always have an overview of all your system parameters and can make changes quickly and easily.
Safety note: Only have this complete system installed and commissioned by a qualified electrician.
