Victron Smartsolar MPPT 100/15 15A 12V 24V charger

This set includes a male and a female MC4-plug. These plugs are original Stäubli MC4-plugs. Details: touchproof, unplugged IP2X protection, plugged IP67 temperature range from -40° to 90°C isolation material: PA snap-in locking-system cable strain relief according to IEC 61984 (06.2001) contact system: MC-contact lamellas contact material: tinned copper flame class:UL94-V0 protection class: II system voltage up to 1000V rated amperage up to 30A

This cable is used to connect a solar system's accumulator to a professional charging regulator. The cable comes with an intigrated fuse which protects your charging regulator and downstream devices in case of a shortcut. Features: Length: 1,5m Fuse: 15A Solid rubber fuse holder with protection cap (splash proof) Cable diameter: 6mm² M8 circular eyelet

ÖLFLEX© solar xls-r t 2x4mm is a radiation crosslinked high-end solar cable made in Germany with optimized cable design is the solar cable -slim, light and robust and saves a lot of time during installation. The twin line can be easily separated into two lines if necessary. Nevertheless, the connection of the two wires is extremely stable if you prefer to leave the cable together.Product featuresWeather/Uv resistant according to hd 605/a1 Ozone resistant according to en 50396 Halogen-free and flame retardant Good notch and abrasion resistance xls-r t= X-Linked Standard-Reduced twin Proven electron beam crosslinked qualityStandard references / approvalsOn request also available as tÜv pv1-f certified version - Ideal for pv stand-alone systemsApplication areasvIdeal for pv stand-alone systems Gable and flat roof photovoltaic systems Photovoltaic or solar field systems Flexible or building-integrated pv systemsBenefitsEasy to separate into two individual lines Reduced outer diameters enable space- and weight-saving installation Robust against mechanical impact Reduction of fire propagation and toxic smoke gas formation in the event of fire Exact quantity control during installation thanks to meter marking on the cable jacketStructureFine stranded, tinned copper conductor Core insulation made of radiation crosslinked copolymer Outer sheath made of radiation crosslinked copolymer Outer sheath color: black Cores connected in parallel with separating webtechnical dataCore ID code: black / red blue / red Classification: EtIM 5.0 Class ID: ec001578 EtIM 5.0 Class description: Flexible cable Conductor stranding: Fine-stranded according to vde 0295, class 5 / iec 60228 Cl.5 Minimum bending radius: Fixed installation: 4 x outer diameter Rated voltage: AC u0/u : 600/1000 v dc u0/u : 900/1500 v max. permissible system voltage: dc 1.8 kv (conductor-conductor, not grounded system) Test voltage: AC 6500 v Temperature range: 40°C to +100°c max. conductor temperature: 40°C to +100°c Conductor temperature ÖLFLEX© solar xls-r t 2x4mm is a radiation crosslinked high-end solar cable made in Germany with optimized cable design the solar cable is -slim, light and robust and saves a lot of time during installation. The twin line can be easily separated into two lines if necessary. Nevertheless, the connection of the two wires is extremely stable if you prefer to leave the cable together.Product featuresWeather/Uv resistant according to hd 605/a1 Ozone resistant according to en 50396 Halogen-free and flame retardant Good notch and abrasion resistance xls-r t= X-Linked Standard-Reduced twin Proven electron beam crosslinked qualityStandard references / approvalsOn request also available as tÜv pv1-f certified version - Ideal for pv stand-alone systemsApplication areasvIdeal for pv stand-alone systems Gable and flat roof photovoltaic systems Photovoltaic or solar field systems Flexible or building-integrated pv systemsBenefitsEasy to separate into two individual lines Reduced outer diameters enable space- and weight-saving installation Robust against mechanical impact Reduction of fire propagation and toxic smoke gas formation in the event of fire Exact quantity control during installation thanks to meter marking on the cable jacketStructureFine stranded, tinned copper conductor Core insulation made of radiation crosslinked copolymer Outer sheath made of radiation crosslinked copolymer Outer sheath color: black Cores connected in parallel with separating webtechnical dataCore ID code: black / red blue / red Classification: EtIM 5.0 Class ID: ec001578 EtIM 5.0 Class description: Flexible cable Conductor stranding: Fine-stranded according to vde 0295, class 5 / iec 60228 Cl.5 minimum bending radius: fixed installation: 4 x outer diameter nominal voltage: AC u0/u : 600/1000 v dc u0/u : 900/1500 v max. permissible system voltage: dc 1.8 kv (conductor-conductor, not grounded system) test voltage: AC 6500 v temperature range: 40°C to +100°c max. conductor temperature

Color Control GXThe Color Control (CCGX) provides intuitive control and monitoring for all products connected to it. The list of Victron products that can be connected is endless: Inverters, Multis, Quattros, all our latest MPPT solar chargers, BMV-700, BMV-600, Lynx Ion+ Shuntand more. VRM Online PortalBesides monitoring and controlling products on the CCGX, the information is also forwarded to the free remote monitoring website: the VRM Online Portal. To get an impression of the VRM Online Portal, visit https://vrm.victronenergy.com, and try the demo. See also the screenshots in the datasheet.Future functionalityThe CCGX has endless possibilities. To implement all the ideas and wishes will take years. There are therefore many features that are not yet available. Functions marked with ‘Future function’ will become available later on, as a firmware update. Firmware updates are free of charge, as with all updates of Victron products. Updating the product is easy: the CCGX will update itself automatically, as long as it is connected to the internet. Manual updates can be done with a USB stick and microSD cards.Supported products Multis and Quattros, including split phase and three-phase systems. Monitoring and control (on/off and current limiter). Changing settings is not yet available. BlueSolar MPPT 150/70 and the MPPT 150/85. Current solar output is visible on the overview screen, and all parameters are logged to the VRM online portal. Note that the VRM App has a nice overview showing data of the BlueSolar MPPT 150/70 as well. When multiple BlueSolar MPPTs with VE.Can are used in parallel, the Color Control will show all information as one. BlueSolar MPPT Solar Chargers with a VE.Direct port (70/15, 75/15, 100/15, 100/30, 75/50, 100/50, 150/35) can be connected to the VE.Direct ports on the CCGX. Connecting multiple at the same time is possible. They will all appear as a separate Solar Charger in the device list. BMV-700 family can be connected directly to the VE.Direct ports on the CCGX. Use the VE.Direct Cable for this. BMV-600 family can be connected to the VE.Direct ports on the CCGX. Use the VE.Direct to BMV60xS cable for that. Lynx Ion + Shunt Lynx Shunt VE.Can Skylla-i NMEA2000 tank sensors A USB GPS can be connected to the USB port. Location and speed will be visible on the display, and the data is sent to the VRM Portal for tracking purposes. The map on VRM will show the latest position. WiFi USB.  Note that there are more options for products which use the VE.Direct ports, such as BMVs and small MPPTs. They can also be connected through USB, useful when more than two products need to be connected. Use an off-the-shelf USB-hub and the VE.Direct to USB interface, ASS030530000.Other highlightsWhen connected to the internet, the CCGX will update itself automatically when there is a new software version available.Multiple languages: English, Chinese, German, Italian, Spanish, French, Swedish and Dutch.Use the CCGX as a Modbus-TCP gateway to all connected Victron products.Notes for existing VGR2 and VER usersOpposite to the Victron Global Remote 2 (VGR2) and Victron Ethernet Remote (VER), the CCGX stores all data locally during network interruptions. As soon as the connection to the VRM Online Portal is restored, it will automatically send all backlogged data to the portal. Data can then be analysed on https://vrm.victronenergy.com. The local website, as present on the VER, is not yet supported.The CCGX has no internal GPRS modem: you cannot insert a sim-card into the CCGX. Use an off-the-shelf GPRS or 3G router instead.

The Victron MPPT Control (MPN SCC900500000) is a solar computer / remote panel that enables you to cofigure and analyze every BlueSolar MPPT charge controller (except the 75/15) with integrated VE.Direct-port.This panel makes configuration and monitoring of your charge controller and its performance parameters more comfortable and easier. Extensive display and control optionsThe MPPT Control provides a wide range of data and values that allow the user a deep look into the charge controller's operation performance. It is not only possible to see the current data but also historical ones which are saved for 30 days in the device's internal storage. Besides current and historical performance data this panel offers even more: the internal storage also holds information about the length of single charging modes like "bulk", "absorption" and "float". This is unique in this price class! Displayed values in Live-Status mode solar module performance in W solar module voltage in V daily output in kWh current charging mode: (OFF, FAULT, BULK, ASORPTION and FLOAT) charging-and discharging current of the battery errors (only when errors occur) battery voltage consumer output status ON/OFF (only on BlueSolar MPPTs with consumer output) consumption on consumer output (only on BlueSolar MPPTs with consumer output) Historical data (30 days) total output in kWh max. module voltage max. battery voltage min. battery voltage last errors Displayed values in 24h-mode daily time exposure for bulk mode daily time exposure for absorption mode daily time exposure for float mode min. battery voltage 24h max. battery voltage 24h max. solar voltage 24h last error Equipment neededTo connect the MPPT Control to your BlueSolar MPPT you need a VE.Direct connection cable - of course also available in our shop. Different ways of installation for the MPPT ControlWith help of the included mounting frame the MPPT Control can be installed directly into a control panel or terminal box. Optionally there is also an according wall-mounting bracket.No matter which of these options you chose a professional high-quality look is guaranteed. Delivery scope:1x Victron SCC900500000 MPPT Control
